Operation Manual
Table Of Contents
- en Instruction manual
- Table of contentsen Instruction manual
- : Important safety information
- Read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual and installation instructions for future use or for subsequent owners.
- This appliance is only intended to be fully fitted in a kitchen. Observe the special installation instructions.
- Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.
- Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.
- This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
- This appliance is intended for use up to a maximum height of 2000 metres above sea level.
- This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
- Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
- Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
- Always slide accessories into the cooking compartment correctly. See "Description of accessories in the instruction manual.
- Mechanical abrasion on baking trays can cause some of the aluminium to be removed, and acidic, alkaline and salty foods can cause the aluminium to dissolve, for example due to fruit acid or baked goods dipped in a lye solution. Do not place food dire...
- Risk of fire!
- Risk of burns!
- Risk of scalding!
- Risk of injury!
- Risk of electric shock!
- ■ Incorrect repairs are dangerous. Repairs may only be carried out by one of our trained after-sales engineers. If the appliance is faulty, unplug the mains plug or switch off the fuse in the fuse box. Contact the after-sales service.
- Risk of electric shock and serious injury!
- Risk of electric shock!
- Risk of electric shock!
- Risk of electric shock!
- Causes of damage
- : Important safety information
- Your new oven
- Your accessories
- Before using the oven for the first time
- Setting the oven
- Types of heating and temperature
- The oven should switch off automatically
- 1. Use the function selector to select the required type of heating.
- 2. Use the temperature selector to set the temperature or the grill setting.
- 3. Press the 0 clock button. The x Cooking time symbol flashes.
- 4. Use the + or - button to set the cooking time. Default value for + button = 30 minutes Default value for - button = 10 minutes
- The cooking time has elapsed
- Changing the setting
- Cancelling the setting
- Setting the cooking time if the clock is hidden
- The oven should switch on and off automatically
- 1. Use the function selector to select the required type of heating.
- 2. Use the temperature selector to set the temperature or the grill setting.
- 3. Press the 0 clock button. The x Cooking time symbol flashes.
- 4. Use the + or - button to set the cooking time.
- 5. Press the 0 Clock button repeatedly until the yEnd time symbol flashes. You can see in the display when the meal will be ready.
- 6. Use the + button to set a later end time. The setting is adopted after a few seconds. The display shows the end time until the oven starts operating.
- The cooking time has elapsed
- Note
- Setting the clock
- Setting the timer
- Childproof lock
- Care and cleaning
- Notes
- Cleaning agents
- Detaching and refitting the rails
- Detaching and attaching the oven door
- Removing and installing the door panels
- Removal
- 1. Detach the oven door and lay it on a cloth with the handle facing down.
- 2. Pull off the cover at the top of the oven door. Press in the tabs on the left and right using your fingers (fig. A).
- 3. Lift the top panel up and pull it out (fig. B).
- 4. Lift the panel up and pull it out (fig. C).
- : Risk of injury!
- Installation
- Removal
- Troubleshooting
- After-sales service
- Energy and environment tips
- Tested for you in our cooking studio
- Notes
- Cakes and pastries
- Baking tips
- Meat, poultry, fish
- Tips for roasting and grilling
- Bakes, gratins, toast with toppings
- Preprepared products
- Special dishes
- 1. Bring 1 litre of milk (3.5% fat) to the boil, let it cool to 40 °C.
- 2. Add 150 g yoghurt (from the refrigerator) to the milk and stir well.
- 3. Pour into small sealable jars and cover with cling film.
- 4. Place the jars on a wire rack and slide in at level 1.
- 5. Set the baking temperature to 50 °C and continue as indicated.
- 1. Prepare the yeast dough as usual, place it in a heat-resistant ceramic dish and cover with a lid.
- 2. Preheat the oven as indicated.
- 3. Close the oven door and allow the yeast dough to prove in the oven.
- Defrosting
- Drying
- Preserving
- Acrylamide in foodstuffs
- Test dishes
18
Tips for roasting and grilling
Bakes, gratins, toast with toppings
If you are grilling directly on the wire rack, the universal pan
should also be inserted at level 1. This keeps the oven cleaner.
Always place the ovenware on the wire rack.
How well cooked the bake is will depend on the size of the dish
and the height of the bake. The figures in the table are only
average values.
Preprepared products
Observe the instructions on the packaging.
If you line the accessories with greaseproof paper, make sure
that the paper is suitable for these temperatures. Make sure the
paper is a suitable size for the dish to be cooked.
The cooking result greatly depends on the quality of the food.
Pre-browning and irregularities can sometimes even be found
on the raw product.
Note
The universal pan may warp when cooking frozen dishes. The reason for this is the large temperature differences that the
accessory is subjected to. The deformation disappears as early as during the cooking process.
The table does not contain information
for the weight of the joint.
Select the next lowest weight from the instructions and extend the time.
How to tell when the roast is ready. Use a meat thermometer (available from specialist shops) or carry out a “spoon test”.
Press down on the roast with a spoon. If it feels firm, it is ready. If the spoon can be
pressed in, it needs to be cooked for a little longer.
The roast is too dark and the crackling
is partly burnt.
Check the shelf height and temperature.
The roast looks good but the juices are
burnt.
Next time, use a smaller roasting dish or add more liquid.
The roast looks good but the juices are
too clear and watery.
Next time, use a larger roasting dish and use less liquid.
Steam rises from the roast when basted. This is normal and due to the laws of physics. The majority of the steam escapes through
the steam outlet. It may settle and form condensation on the cooler switch panel or on
the fronts of adjacent units.
Dish Accessories and
ovenware
Level Type of
heating
Temperature, °C Cooking time
in minutes
Bakes
Bake, sweet Ovenproof dish 2
%
170-190 50-60
Pasta bake Ovenproof dish 2
%
210-230 25-35
Gratin
Potato gratin made using raw ingredients,
Max. 2 cm deep
Ovenproof dish 2
4
150-170 50-60
Toast
Toasting bread, 4 slices Wire rack 4
*
3 6-7
Toasting bread, 12 slices Wire rack 4
(
3 4-5
Toast, with topping, 4 slices Wire rack 3
*
3 7-10
Toast, with topping, 12 slices Wire rack 3
(
3 5-8
Dish Accessories Level Type of
heating
Temperature,
°C
Cooking time
in minutes
Strudel with fruit filling Universal pan: 3
2
180-200 40-50
Chips Universal pan: 3
%
210-230 25-30
Pizza Wire rack 2
%
200-220 15-20
Pizza baguette Wire rack 2
4
190-210 15-20
