Technical data

Installation Instructions Linear Smoke Detector Fireray 50/100RV
ST/PMF/zab
610-F.01U.002.706 / A2.en
Page 10 of 14
4. Technical Data
Operating voltage 10 V DC . . . 30 V DC
Current consumption:
- in standby mode
< 4 mA @ 24 V
- in standby mode
- in alarm/malfunction
< 4 mA @ 24 V
< 15 mA
Reset control by power disruption > 5 s
Alarm relay Normally open; dry
contact
(2 A @ 30 V DC)
Fault relay Normally close; dry
contact
(2 A @ 30 V DC)
Permissible distance between Fireray and the
reflector:
- Fireray 50RV
- Fireray 100RV
5 m to 50 m
50 m to 100m
Optical wavelength 880 nm
Adjustable alarm threshold values 2.50 dB (25%)
3.74 dB (35%)
6.02 dB (55%)
Axial deviation tolerance
(at 35% sensitivity)
Detector $0.8
Prism reflector $5.0
Operating temperature -30C . . . +55C
Protection type IP 50
Dimensions (W x H x D) 126 x 210 x 120 mm
Weight 670 g
Housing:
- Color
- Material
light gray/black
ABS, non-flammable
VdS ID number G 203070
5. Additional Documentation
For those with access authorization, on the Bosch ST ExtraNet at
www.boschbest.de
the current information for each product, as well as the installation instructions
supplied with the device, are available for download as a PDF file.
