Conettix ITS-D6682-INTL | Installation Guide | 4.0 Specifications
.
Bosch Security Systems, Inc. | 2/09 | F01U126778-01 11
4.0 Specifications
Table 3: Specifications
Supported
Protocols
ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP, and HTTP
Connectors
Serial: 2 - DB9M DTE serial ports
Network: 1 - RJ45 10Base-T/100Base-TX Ethernet port
Cables
Ethernet: CAT5 or better unshielded twisted pair
Max Length: 100 m (328 ft) and installed in same enclosure/rack as
D6600.
RS-232: Max Length: 15 m (50 ft) and installed in same enclosure/rack as D6600.
Data Rates Serial speed ranging from 300 bps to 115.2 kbps
Serial Line Formats
Characters 7 or 8 data bits
Stop bits: 1 or 2
Parity: Odd, even, none
Modem Controls DTR, DSR
Flow Control Software: XON/XOFF
Hardware: CTS/RTS
Management HTTP (internal web server)
SNMP (read only)
Serial login
Telnet login
DeviceInstaller software
System Software Flash ROM standard: downloadable from a TCP/IP host (TFTP) or over serial port
Diagnostic LEDs Power
10/100 Mb Link on RJ45, 10/100 Activity on RJ45
RX Serial 1 Activity, TX Serial 1 Activity, RX Serial 2 Activity, TX Serial 2 Activity
Compatibility Ethernet: v2.0/IEEE 802.3
D6600
AC Current
Required
UPS Standby Current: 0.4 A
Power Input AC nominal operating range: 100 to 240 VAC, 50/60 Hz, 0.4A max
Environmental
Operating Temperature: 0° to 50° C (32° to 122° F)
Storage Temperature: -40° to 85° C (-40° to 185° F)
Dimensions (H x W x D):
Unit: 3.75 in. x 2.9 in. x .9 in. (9.5 cm x 7.3 cm x 2.3 mm)
Weight 0.6 lbs. (0.26 kg)
