Conettix ITS-D6682-INTL Installation Guide EN Ethernet Network Adapter
Conettix ITS-D6682-INTL | Installation Guide | Contents Contents 1.0 1.1 1.2 1.3 2.0 2.1 2.2 3.0 3.1 3.2 3.3 3.4 3.5 3.6 3.7 4.0 2 Introduction...................................................... 3 Network Interface.............................................. 3 Serial Interface.................................................. 3 LEDs ................................................................. 3 Installation........................................................ 4 Mounting the D6682............
Conettix ITS-D6682-INTL | Installation Guide | 1.0 Introduction . Trademarks Microsoft® Windows® 2000, XP, Vista™, and MS-DOS®, are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. 1.2 Serial Interface Figure 2: D6682 Network Interface 1.0 Introduction The Conettix D6682 Ethernet Network Adapter is a two-channel network adapter. Most networked installations only have one configured channel.
Conettix ITS-D6682-INTL | Installation Guide | 2.0 Installation 2.0 Installation 2.1 Figure 3: D6682 Connections Mounting the D6682 Mount the D6682 on a rail or other user-supplied spot behind the D6600 that it will be connected to. Refer to Figure 3. 2.
Conettix ITS-D6682-INTL | Installation Guide | 3.0 Configuring and Programming the D6682 . 3.0 Configuring and Programming the D6682 3.1 Factory Default IP Address By default, the D6682 uses DHCP to obtain an IP Address. The unit requires a static IP Address. Refer to Sections 3.2, 3.3, and 3.4 for more information. 3.2 Identifying the MAC Hardware Address 1. Verify that the D6682 is properly installed, connected, and powered. Refer to Section 2.0 Installation on page 4. 2.
Conettix ITS-D6682-INTL | Installation Guide | 3.0 Configuring and Programming the D6682 3.5 ARP Command Usage Perform the following procedure when using the ARP command to assign an IP address to a D6682. The MAC address shown below is used as an example. 00-20-4a-12-04-0e 3. Type the arp –s command with the IP address and the MAC hardware address. For this example the IP address is 190.220.128.
Conettix ITS-D6682-INTL | Installation Guide | 3.0 Configuring and Programming the D6682 . 3.6 Using Telnet to Finish the Configuration Although the screen shots are specific to Windows 2000, they are similar for Windows XP and Vista. In Windows Vista, Telnet is disabled by default. In order to use Telnet, you must enable it: A DOS window appears: 1. Click Start→Control Panel→Programs. 2. Click Turn Windows features on or off.
Conettix ITS-D6682-INTL | Installation Guide | 3.0 Configuring and Programming the D6682 12. If you pressed [ENTER] within five sec, you should see the following screen. Refer to Figure 9. Figure 9: Telnet Session 15. When asked to set the Gateway IP address (Figure 10), type N and press [ENTER] to accept the default. Figure 10: Telnet session – Gateway Address The Gateway IP address is needed with a wide area network (WAN). In a local area network (LAN), the Gateway is usually not needed. 13.
Conettix ITS-D6682-INTL | Installation Guide | 3.0 Configuring and Programming the D6682 . 19. Press [1] [ENTER] to configure Channel 1. Baudrate 9600 appears. Table 2: Netmask Address Number of Host Bits 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 Netmask 255.255.255.254 255.255.255.252 255.255.255.248 255.255.255.240 255.255.255.224 255.255.255.192 255.255.255.128 255.255.255.0 255.255.254.0 255.255.252.0 255.255.248.0 255.255.240.0 255.255.224.0 255.255.192.
Conettix ITS-D6682-INTL | Installation Guide | 3.0 Configuring and Programming the D6682 27. If you want to enable encryption, select 6 Security from the main menu and continue with Step 28. If encryption is enabled on the D6682 (refer to Figure 11), you must enable it on all field devices (C900TTL-E, D9133TTL-E, DX4020) with the same key. Encryption must also be enabled in the D6600 Receiver. Refer to the D6600 Program Entry Guide (P/N: 4998122702).
Conettix ITS-D6682-INTL | Installation Guide | 4.0 Specifications . 4.
Bosch Security Systems, Inc. 130 Perinton Parkway Fairport, NY 14450-9199 (800) 289-0096 © 2009 Bosch Security Systems, Inc.
