BORK - VC SHB 9919 BK & VC SHB 91 1 24.10.
VAC U U M C L E AN ER BORK VC SHB 9919 BK/VC SHB 9818 BL BORK - VC SHB 9919 BK & VC SHB 92 2 24.10.
CONTENT 5 Safety recommendations from BORK company 6 Technical parameters 7 Configuration 8 Special features 11 Operating 15 Care and cleaning 18 Troubleshooting 3 BORK - VC SHB 9919 BK & VC SHB 93 3 24.10.
Congratulations on the purchase of your new vacuum cleaner BORK VC SHB 9919 BK/VC SHB 9818 BL BORK - VC SHB 9919 BK & VC SHB 94 4 24.10.
SAFETY RECOMMENDATIONS FROM BORK COMPANY BORK company draws much attention to safety matters. We design and manufacture our products striving to provide maximal safety for you. In addition, we ask you to follow simple safety recommendations when using any electrical appliances. READ ALL INSTRUCTIONS BEFORE OPERATING AND SAVE THEM FOR FUTURE REFERENCE When using the vacuum cleaner, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER.
TECHNICAL PARAMETERS Voltage: 230 V Power Supply: 50 Hz Power Consumption: 1900 Вт (VC SHB 9919 BK) 1800 Вт (VC SHB 9818 BL) WARRANTY The benefits conferred by this warranty are in addition to all implied warranties, other rights and remedies in respect of the product which the consumer has under the Trade Practices Act and Territory Laws.
CONFIGURATION Cleaner Hose Caddie accessory holder. Contains a combined brush and a telescopic crevice nozzle. Carpet/hard floor nozzle Telescopic crevice nozzle Combined brush Turbo nozzle BORK Clinic dust bag Textile dust bag Telescopic tube Not presented on photo: Instruction manual Warranty card CONFIGURATION BORK - VC SHB 9919 BK & VC SHB 97 7 1 1 7 24.10.
SPECIAL FEATURES Electronic power control on the body Filter O2 of the standard HEPA H12 Dust bag full indicator BORK Clinic dust bag Overheat protection of the cleaner 440 aW suction power 8 SPECIAL FEATURES BORK - VC SHB 9919 BK & VC SHB 98 8 24.10.
BORK - VC SHB 9919 BK & VC SHB 99 9 24.10.
Operating 10 BORK - VC SHB 9919 BK & VC SHB 910 10 24.10.
ASSEMBLING VACUUM CLEANER & OPERATION 1 2 5 BEFORE STARTING 1 Check that the BORK Clinic is in place. 2 Insert the hose until the catch clicks to engage (press the catch to release the hose). 3 Attach the telescopic tube to the hose handle and the floor nozzle (to disconnect, press the lock button and pull apart). 4 The hose can easily be removed from the handle by pressing the retaining button and pulling out the hose. 3 6 4 7 5 Pull out the cable and plug it in.
ASSEMBLING VACUUM CLEANER & OPERATION 1 2 5 3 6 GETTING THE BEST RESULTS Hard floors: Use the carpet/hard floor nozzle with the left pedal in position (1). Frames, bookshelves, etc.: Use the combination nozzle as shown in (4) or feather duster. Carpets: Use the carpet/hard floor nozzle with the left pedal in position (2). Crevices, corners, etc.: Use the extended crevice nozzle (5). Extend the crevice nozzle using a finger to push out the extending section.
ASSEMBLING VACUUM CLEANER & OPERATION 1 2 3 THE CLEANER SAVES YOUR BACK WHILST CLEANING YOUR HOME 1. To save your back, the cleaner features a flexible handle that makes it easier to lift and carry the machine. 2 Additionally, the convenient parking position helps when you take a break during vacuuming. 3 Parking position for storage. ASSEMBLING VACUUM CLEANER & OPERATION BORK - VC SHB 9919 BK & VC SHB 913 13 13 24.10.
Care and cleaning 14 BORK - VC SHB 9919 BK & VC SHB 914 14 24.10.
CARE AND CLEANING 1a (VC SHB 9818 BL) 1b (VC SHB 9919 BK) 2 3 4 5 6b 6a REPLACING THE DUST BAG BORK CLINIC 1. Replace the BORK Clinic as soon as the indicator window becomes fully red (1a) or when the window lights up (1b). 2 Remove the hose and open the lid. 3 Pull the cardboard holder to remove the BORK Clinic. This automatically closes the dust bag and stops dust from leaking out. 4 Insert a new BORK Clinic by pushing the cardboard holder straight down in its tracks. Close the lid.
CARE AND CLEANING 1 CLEANING THE HOSE AND NOZZLE The vacuum cleaner stops automatically if the nozzle, tube or hose becomes blocked, if the filter and dust bag are blocked or if the overheat indicator starts flashing (1). Disconnect from the mains and allow the vacuum cleaner to cool for 20-30 minutes. Clear what is causing the stoppage and/or replace dirty filters or the full BORK Clinic. Then restart the vacuum cleaner. 16 2 3 Tubes and hoses 2.
CARE AND CLEANING 6 7 Larger objects can be removed by taking off the connecting tube (press in the small catches and remove the tube). 8 Remove the object and replace the connecting tube. 7 8 9 Cleaning the turbo nozzle 9. Remove the nozzle from the vacuum cleaner tube and remove entangled threads etc. by snipping them away with scissors. Use the hose handle to vacuum the nozzle. CARE AND CLEANING BORK - VC SHB 9919 BK & VC SHB 917 17 17 24.10.
TROUBLESHOOTING TROUBLESHOOTING AND CONSUMER INFORMATION The vacuum cleaner does not start 1 Check that the cable is connected to the mains. 2 Check that the plug and cable are not damaged. 3 Check for a blown fuse. CONSUMER INFORMATION BORK decline all responsibility for all damages arising from any improper use of the appliance or in cases of tampering with the appliance. This product is designed with the environment in mind. All plastic parts are marked for recycling purposes.
