Specification Sheet

The illustrations and descriptions herein are applicable to production as of the date of this Technical Data Sheet. B-7125 10/26/17 Printed in U.S.A.
The manufacturer reserves the right to, and does from time to time, make changes and improvements in designs and dimensions. © 2017 by Bobrick Washroom Equipment, Inc.
OPERATION:
Infrared sensor automatically turns dryer on when hands are held under air-outlet opening and across path of sensor. Remove hands from
path of sensor and dryer stops. Electronic sensor has automatic shutoff approximately 85 seconds after dryer turns on if an inanimate object is
placed across air-outlet opening. After inanimate object is removed, electronic sensor automatically resets itself and dryer operates normally.
5-Year Limited Warranty — In addition to Bobrick’s one-year guarantee, Bobrick extends a limited 5-year warranty from the date of
purchase on all parts for model B-7125. This warranty is limited to the repair or exchange of defective parts at the option of Bobrick and is only
extended to the original owner of the installed unit against defects in factory workmanship or material under normal use and service.
INSTALLATION:
Wall preparation — Locate mounting base on wall using template provided. For brick, stone, and concrete walls drill four 0.315" (8mm) holes
to suit provided wall plugs 0.315" x 1-1/4" (8 x 45mm) and screws # 10 x 2" (4.8 x 50mm) long. See template for wall plug and screw installation
details. For plaster or dry wall construction, provide concealed backing to comply with local building codes and secure with four #10 (4.8)
round-head sheet-metal screws or 3/16" (5mm) toggle bolts (not furnished). Provide electrical service from nearest distribution panel to dryer
mounting base in conformance with local electrical codes.
Dryer Wiring Instructions:
1. For 115-Volt Dr yers — Connect ground wire to ground terminal marked
, the black or hot wire to terminal marked L1, and neutral or
white wire to terminal marked N.
2. For 208–240-Volt Dr yers —
Connect ground wire to ground terminal marked and the 208- or 240-volt wires to terminal marked L1 and L2.
3. This is a class 1 product and requires grounding.
Notes: Electronic sensor in Automatic dryers will pick up movement within 6" (150mm) of the air-outlet opening. Use caution when choosing
location for Automatic dryers in confined areas. Consider proximity to doorways and other traffic areas. Bobrick automatic hand dryers should
be installed at least 19-3/4" (500mm) above any projection or horizontal surface which may interfere with the operation of the automatic
sensor.
Replacement Parts:
Cover 7125-150
Controller 7125-25
Controller Loom (Wiring) 7125-30
SAFETY WARNING:
Installation and wiring must conform to current local regulations and building codes. Unit must
be installed by a qualified electrician. Turn off electrical power supply before making electrical
connections. If the unit fails or malfunctions, it should be disconnected from the power supply and
a qualified electrician should be called. To avoid potential injury, the building owner or maintenance
personnel should remove the unit from ser vice if the grille is missing or damaged.
SPECIFICATION:
Surface-mounted high-speed hand dryer shall have an energy consumption of only 200 watts. Unit shall have 18-gauge (1.2mm) thick Type-304
stainless steel cover with #4 satin finish vertical grain. The slim profile cover shall project no more than 3 7/8" (98mm) from the finished
face of wall to comply with accessible design guidelines (including ADAAG in the U.S.A.) and have a dry time of less than 12 seconds. Dryer
shall be universal, to accommodate voltages between 110-240V. Dryer shall be secured to concealed mounting bracket with vandal-resistant
screws. Electronic sensor automatically turns dryer on when hands are held under air-outlet opening and across path of sensor. Dryer turns
off automatically when hands are removed. Sensor automatically shuts dryer off approximately 85 seconds after dryer turns on if an inanimate
object is placed across air-outlet opening. After object is removed, electronic sensor automatically resets itself and dryer operates normally.
Unit is cULus listed and is CE marked. Dryer has a limited 5-year warranty on all parts.
InstaDry Surface-Mounted Automatic Hand Dryer shall be Model B-7125 of Bobrick Washroom Equipment, Inc., Clifton
Park, New York; Jackson, Tennessee; Los Angeles, California; Bobrick Washroom Equipment Company, Scarborough, Ontario;
Bobrick Washroom Equipment Pty. Ltd., Australia; and Bobrick Washroom Equipment Limited, United Kingdom.
