Waste / Recycle Sets

Bin width and height must be considered
when designing your cabinet (see the
diagram on the left).
Drawer front attachment
Typical panel
Typical face frame
Cabinet bottom recess
6 (1/4") 3 (1/8") Flush
Y 16 (5/8") 19 (3/4") 22 (7/8")
Minimum inside cabinet depth
With SERVO-DRIVE 574 (22-19/32")
Without SERVO-DRIVE 569 (22-13/32")
Front view
NOTE: Minimum opening height = 233 (9-3/16")
Drawer and cabinet specifications
Important
minimum top
clearance
6 (1/4")
16 (5/8") maximum
bottom clearance depending
on cabinet bottom recess
opening width
opening height
maximum height
with bin =
opening height
minus 22 (7/8")
16 (5/8")
X
X
=
0
96
(3-25/32")
64
(2-17/32")
32
(1-1/4")
X
+
overlay minus 2 (3/32")
Y + overlay
Dimensions in millimeters (inch equivalents as noted) © 2011 Blum, Inc.
5
Specifications
SERVO-DRIVE
inside
BLUMOTION
inside
Waste/recycle set 356M55B7SAB 356M55B7SAD 356M55B7SAF
Z 146.5 (5-25/32") 184.5 (7-1/4") 222.5 (8-3/4")
Min. opening width 305 (12") 381 (15") 457 (18")
Set mounting specifications
Top view
NOTE:
Orange dots indicate pre-mounted screw locations. All four are required to meet
specified load capacities.
417 (16-13/32")
45
(1-25/32")
37.5
(1-15/32")
559 (22")
minimum inside cabinet depth
4 (5/32")
Z
37.5
(1-15/32")
centerline of cabinet
