Drawer insertion and removal

Insertion Removal

Drawer adjustment

Height adjustment Side adjustment Tilt adjustment

Use a Phillips screwdriver to adjust drawer

front up or down as shown (+/- 2 mm).

Repeat on left side if necessary.

Use a Phillips screwdriver to adjust

drawer front left or right (+/- 2 mm). Adjust

left or right side equally by turning both

toward or away from drawer front.

Slide gallery cover towards drawer back.

Rotate orange adjustment piece as shown

and slide cover back towards drawer

front. Repeat on left side if necessary.

© 2011 Blum, Inc. Subject to technical modiﬁcations without notice.

10

TANDEMBOX adjustments

Bin conﬁgurations

15" wide cabinet — one bin 18" wide cabinet — two bins 21" wide cabinet — two bins

Accommodates a wide range of standard bin sizes.
