Drawers, Hinges & Assembly Devices
DRILLING TEMPLATE FOR SPACE CORNER WITH SYNCROMOTION
• Template for drilling the fixing positions for the SPACE CORNER SYNCROMOTION fittings
DRILLING TEMPLATE FOR TIP-ON FOR TANDEMBOX
• Template for pre-drilling the fixing positions for the locking mechanism and synchronisation unit
• Drilling template can be used with assembled and unassembled drawers
• Assembly on a marking line
• Includes 1 x drilling depth stop 5mm
• Includes 1 x reducing bush 5mm to 2.5mm
• Includes 1 x Allen Key
Position the drilling template in
the corner and drill for the front
SYNCRO fiting
TIP-ON assembly – Locking
mechanism unit
Position template on unattached
drawer base or on drawer side
(attached 3-sided drawer)
Drill fixing positions for locking
mechanism unit
Place drilling template on the
side and drill for corner front
piece
TIP-ON assembly –
Synchronisation unit
Position template on drawer base
on marking line
Pre-drill fixing positions for
synchronisation unit (Ø 2.5 mm)
Complete drilling pattern
Description Material Blum No. Code
Drilling Template For SPACE
CORNER With SYNCROMOTION
Nylon/Steel
ZML.0330 1-285-690
Description Material Blum No. Code
Drilling Template for TIP-ON for
TANDEMBOX
Nylon/Steel/Aluminium
65.5050 1-285-697
DRAWER ASSEMBLY DEVICES
SYNCROMOTION Drilling
