MINIPRESS PRO - VERSATILE
MINIPRESS PRO
• Take advantage of the MINIPRESS PRO’s versatility for easy vertical cabinet,
door and front drilling.
• Blum hardware fittings can be assembled with absolute workshop precision
and efficiency thanks to the quick and easy MINIPRESS PRO options.
• MINIPRESS PRO has many components so you can customise the amount of
applications you would like to achieve.
Colour Codes Simplify Set Up
The set-up of MINIPRESS PRO is simple with colour
coded drilling heads, rulers and set up plan all
matching.
Practical and Precise Ruler System
The ruler drilling distance is set with the easy to use
and read calibrated spindle.
Easy to Read Charts
Each work step is illustrated systematically and
colour coded in the set-up plan.
Simple Tool Free Ruler Connection
The dedicated ruler with colour coded stops can be
fitted in a matter of seconds without the need for
tools.
Pre Equipped Colour Coded Drilling
Heads
The pre-equipped drilling head, which is also colour
coded per application, is inserted and secured using
a locking device without the need for tools.
Pre Set Depth Settings
The drilling depth can be pre-set on fixed positions
using the colour coded revolving handle (revolving
stop).
Description Blum No. Code
MINIPRESS PRO, Pneumatic,
Single phase machine. Includes timber
work table and tools
M54.2050 1-340-100
Contact your local Lincoln Sentry Territory Manager for more detail
on the benefits a MINIPRESS PRO can bring to your business.
