TEST JACK CONNECTOR FOR SERVO-DRIVE
• Enables you to easily check the correct cabling of SERVO-DRIVE components using a toolfree, plug-in
connector
• Can only be used with the SERVO-DRIVE transformer
Description Material Blum No. Code
Test Jack Connector for SERVO-DRIVE Nylon/Steel
ZML.1290 1-285-623
Connect transformer to test jack
connector and SERVO-DRIVE
components
Checking SERVO-DRIVE components
The connection and/or cabling of the
individual components is correct when
all LEDs light up on drive units
