Drawers, Hinges & Assembly Devices

DYNALOG

DYNALOG 2.9

• DYNALOG includes 3 modules:

• DYNACAT (CD-ROM product catalogue)

• DYNASHOP (shopping basket)

• DYNAPLAN (cabinet planner)

• Its modular design makes it easy to use and

supports product selection, ordering and cabinet

planning

DYNAPLAN INTERFACE ADVANTAGES

Features:

• The CAD system remains the main program. DYNAPLAN can be opened as an auxiliary program for

special situations

• The interface lets you use the synergies of both programs. You only have to enter the data once

• It makes it easy to plan special cabinets. A collision check is carried out for the planned cabinet

application and its fittings solutions. All relevant information such as wooden parts, drillings and fittings

are exported via the press of a button from DYNAPLAN to the CAD/CAM program

• A manual import is not necessary and you don‘t need to position the individual CAD data in the

construction program

DYNAPLAN – THE CABINET PLANNER

• With DYNAPLAN, you have several options for planning cabinets and ordering the correct fittings

• All required cutting dimensions and fixing positions of fittings are calculated automatically

• An integrated collision check saves costly trial applications

DYNACAT – THE ELECTRONIC PRODUCT CATALOGUE

• DYNACAT supports you during fittings selection and also provides additional, useful information

regarding manufacturing and assembly

• 2D and 3D CAD data for all fittings are available in common formats (dxf, dwg, etc.)

DYNASHOP – THE SHOPPING BASKET

• The fittings determined via DYNAPLAN and DYNACAT can be easily ordered via DYNASHOP

• It also provides additional, useful function creating projects & Lincoln Sentry item code numbers

Using the DYNAPLAN interface, it is possible to export data to various CAD/CAM programs.

If required additional editing is possible to ensure you get the best out of both programs once the DYNAPLAN data has been transferred to your

CAD/CAM program.

Regardless of whether you are using 3D data (dwg, dxf, etc.), exporting your cabinets planned in DYNAPLAN (incl. fittings data and drilling

positions) to a CAD program or even implementing the fittings selection logic from DYNAPLAN in your CAD system – Blum product from Lincoln

Sentry offers customers the right solution.

Description Blum No. Code

DYNALOG 2.9

DAA.2943 1-285-505
