Installation Sheet

6
Subject to technical modifications
without notice. © 2010
less than 6
12.5
19
12.5
ü
Standard mounting plate works
Attaching the telescopic arm mounting plate with bracket for five-piece doors
8b
more than 6
12.5
ü
Standard mounting plate does not work
Use mounting plate with bracket when
panel is
<
6 mm from screw
Assembly
Part no.
175H5F00.01
Telescopic arm mounting plate with bracket
