Installation Sheet

10
Subject to technical modifications
without notice. © 2010
Detaching the telescopic arms
Removal
1
2
Remove covers
Risk of injury from spring-loaded arm
Do not push lever arm down or leave in the down position
Remove mechanism before installing or removing cabinet
WARNING
Release both arms and gently rest the top
door on the loose arms. The tension will hold
the doors up for the next step.
2
1
Warning: Risk of injury
from spring-loaded
telescopic arm!
Maintain control of telescopic arm while
releasing the CLIP mechanism.
