CNUZB00BT001 USER MANUAL
1. PACKAGE CONTENTS 2. PRODUCT OVERVIEW 3. PREPARATIONS INSTALLING THE BATTERY INSERTING THE MEMORY CARD THE LANGUAGE SETTINGS THE DATE AND TIME SETTINGS MONITOR SCREEN DISPLAY 4. USING THIS VIDEO CAMERA TURNING THE CAMERA ON AND OFF CHANGE THE MODE TAKING STILL IMAGES USING THE SELF-TIMER AND BURST SNAPSHOT THE CAMERA IN CAPTURE MODE SETTINGS USING THE ZOOM FUNCTION RECORDING VIDEO CLIP RECORDING AUDIO 5. USING THE MENU IN RECORD MODE MENU IN CAPTURE MODE MENU IN VIDEO MODE SETUP MENU 6.
9. TROUBLESHOOTING 10. SPECIFICATIONS 38 40 Thank you for purchasing this digital video camera. Please read these operating instructions carefully in order to use the digital video camera correctly. Keep the instructions in a safe place, after reading, so you can refer to it later. Precautions Before using the video camera, please ensure that you read and understand the safety precautions described below.
1.
2.
3. Preparations Installing the Battery 1. Open the video camera battery door. 2. Insert three AAA-size batteries with the positive (+) and negative (-) poles matching the directions indicated on the battery cover. 3. Close the battery door.
Inserting the Memory Card This digital video camera has an internal memory, it can take a few pictures and video clips if you want to record more files please use a SD or MMC card. Turn off the camera before inserting or removing the memory card. Be sure to orient the card correctly when inserting it. Never try to force the memory card into the slot when you feel resistance. The memory card has a write protect switch, which used to protect data from accidental deletion.
Format the memory card All data will be deleted including protected files. Be sure to download important files to your computer before formatting. 1: Turn the power on, and set the video camera to the Setup Menu.(See the details on 24 ) 2: Press the UP or DOWN button to select [Format] then press the OK button to launch the submenu. 3: Press the UP or DOWN button to select the item [YES] and then press the OK button to erase all data.
2: Press the UP or DOWN button to select [Language] then press the OK button to launch the submenu. 3: Press the UP or DOWN button to select the desired language and then press the OK button to confirm the setting. 4: Press the MENU button to close the menu. The Date and Time Settings 1: Turn the power on, and set the video camera to the Setup Menu.(See the details on page 24 ) 2: Press the UP or DOWN button to select [Date&Time] then press the OK button to launch the submenu.
Monitor screen display Capture mode 9
Video record mode Playback mode 10
4. Using This Video Camera Turning the Camera On and Off 1. Open the LCD panel. 2. To turn on the camera, hold the POWER button until the LCD screen turns on. 3. Hold the POWER button again will turn the camera off. To save battery power, the video camera automatically turns off when the video camera is idle for a period of time. Press the power button to power the camera back on. You can change the automatically power-off time by setting the function [Power Save] in the Setup menu.
the default capture mode. 2: Press the MODE button to change the mode. Each time the MODE button is pressed the mode icon is changed. Display Title Description Capture mode For taking still photos. Video mode For recording movie clips. Audio mode For recording audio files. Playback mode Preview the record files. Taking still images 1. 2. Turn on the video camera. Press the MODE button to set the video camera to capture mode, the icon 3. appears on the LCD screen.
4. Hold the video camera steady and then press the SHUTTER button completely down to take a picture. • When using the video camera, the number of image available will be displayed on the screen. For example, if the screen displays 18 when the camera is power on, after one photo has been captured, 17 will appear, which means 17 more captures available on this video camera based on the memory card size. If the memory is full, “Memory Full“ will appear on screen.
Using the Self-timer and Burst snapshot Use the self-timer to set a delay from the time the shutter button is pressed to the time the image is shot. Use the burst snapshot to take pictures continuously. 1: Turn the power on and set the video camera to the Capture mode. 2: Press the RIGHT button to change the self-timer mode: each time the RIGHT button is pressed, the icon on the up left corner is changed. 2 seconds: The shutter release will delay for 2 seconds.
second, until the memory is full, if you don’t release the SHUTTER button. 3: Press the SHUTTER button to take picture. • You can also set the self-timer and burst snapshot by the capture menu. See the details on page 20. The Camera in Capture Mode Settings The resolution and quality settings You can select a lower image resolution and quality to have smaller image size, in order to capture more images. Choose a suitable setting, according to the desired image quality and purpose.
The exposure value settings Set the exposure value manually to compensate for unusual lighting conditions such as indirect indoor lighting, dark backgrounds, and strong backlighting. See the details on page 20. Using the Zoom Function This video camera has a digital zoom function that allows you to zoom in or zoom out on subjects. The digital zoom enlarges or shrinks the image using a software process. 1: Turn the video camera on and set it to capture mode or video record mode.
• When the zoom button is pressed, the value of magnification level appears on the LCD monitor. Recording Video Clip 1: Turn the video camera on and set it to video record mode. 2: Press the SHUTTER button to start recording. Press the RIGHT button to have a pause and press it again to continue. 3: Press the SHUTTER button again to end the recording. If the memory is full the video camera will stop recording automatically. • When recording a video, the recorded time will be displayed on the LCD screen.
Recording Audio 1: Turn the video camera on and set it to audio record mode. 2: Press the SHUTTER button to start recording. Press the UP button to have a pause and press it again to continue. 3: Press the SHUTTER again to end the recording. If the memory is full the video camera will stop recording automatically. • When recording an audio, the recorded time will be displayed on the center of the LCD monitor. • There is no menu settings in audio record mode. 5.
Menu in capture mode 1: Turn on the video camera and set it to capture mode. 2: Press the MENU button to display the menu. 3: Use the UP or DOWN button to select an item. 4: Press the OK button to enter the submenu. 5: Use the UP or DOWN button to select the desired item. 6: Press the OK button to confirm the setting. 7: Press the MENU button to close the menu.
Metering Change the metering method to change the brightness of the picture. [Center]: The exposure will be calculated based on light in the center area and this is suitable for general use. [Multi]: The exposure will be calculated based on the average light. [Spot]: Only the spot in the center of the LCD screen will be metered for light. White Adjust the white balance to suit different light sources. Balance There five items for option: [Auto]/ [Daylight] / [Cloudy] / [Fluorescent] / [Tungsten].
Effect Use this function to change the image’s color tone: Normal / B&w / Sepia / Negative / Red / Green / Blue. Date This function can be used to add a date to your pictures as Stamp you take them. There are three items for option: [Off]: Neither date nor time is added to the image. [Date]: Add data to the image. [Date& Time]: Add data and time to the image. Menu in Video Mode 1: In video record mode, press the MENU button to display the menu. 2: Use the UP or DOWN button to select an item.
Menu item Function Movie Size Select small movie size to record longer time. There are three items for option: 720X480/640x480/320X240 Frame Rate Select low frame rate to record longer time. There are two items for option: High/Low. Metering See the details on page 20. White Balance See the details on page 20. Setup Menu You can set the system items in setup menu. 1: Power on and press the MENU button to display the menu. [Setup].
6: Press the OK button to confirm the setting. 7: Press the MENU button to close the menu. Menu item Sounds Function There are four items for option: [Shutter]: Set the shutter sound on or off by pressing the RIGHT button. [Start-up]: Set the start-up sound. Press the RIGHT button to change the sound. There are four options: [None] / [1]/ [2] / [3]. [Beep]: Set the operation sound on or off by pressing the RIGHT button. [Volume]: Adjust the sound volume. You can change it by pressing the RIGHT button.
Power save To save power, the camera is turned off automatically after a period of time. There are four options: [1min.] / [3min.] / [5min.] / [Off ] . Date& Time Refer to page 8. Language Refer to page 7. TV Out TV Out should be set to either NTSC or PAL depending on your region. [NTSC] / [PAL]. USB You can use this camera as a PC camera or removable disk. [PCCAM]: Use as a PC camera; [MSDC]: Use as a removable disk. Start-up You can use your favorite picture as the start-up image.
initial default. [Yes] / [No]. 6. Playback Playback Still Image 1: Turn the camera on, and then press the MODE button until the camera enter playback mode. The latest recorded file appears on the LCD screen. If there are no images stored, a message [No Image] appears. 2: Press the LEFT or RIGHT button to preview the previous or next image. Playing Back Movie Clips 1: Press the LEFT or RIGHT button to select the movie clips you want to playback in playback mode.
Press the RIGHT button to fast forward and press the LEFT button to reverse. Playing Back Audio Files 1: Press the LEFT or RIGHT button to select the audio file you want to playback. 2: Press the Shutter button to start playing. Press the MENU button to end playing. Press the UP button to pause it and press it again to continue. Press the RIGHT button to fast forward and press the LEFT button to back forward.
view the file in full screen. Lock files 1: Press the MENU button in playback mode. 2: Press the UP or DOWN button to select the item [Lock]. 3: Press the OK button to enter the submenu. 4: Use the UP or DOWN button to select the item: [Lock / Unlock one]: Lock / Unlock current file. [Lock All]: Lock all files. [Unlock all]: Unlock all files. 5: Press the OK button to confirm the setting. A dialog box will appear. Using UP or DOWN button to select the item [Yes].
Delete files 1: Press the MENU button in playback mode. 2: Press the UP or DOWN button to select the item [Delete]. 3: Press the OK button to enter the submenu. [ One]: Delete current file. [All]: Delete all files except locked files. 4: Use the UP or DOWN button to select the item. 5: Press the OK button to confirm the setting. A dialog box will appear. Using UP or DOWN button to select the item [Yes]. 6: Press the OK button to delete the current file or all files.
range of interval time is 1 second to 10 seconds. [Repeat]: Press the LEFT or RIGHT button to set the repeat function on or off. 4: Use the UP or DOWN button to select [Start]. 5: Press the OK button start slide show. 6: Press the MENU button to end slide show. • Only the still image can be show in slide show. Effect Refer to page 21. Rotate the image 1: Select an image you want to rotate in playback mode. 2: Press the MENU button to display the menu.
Save: Select this item to save the rotated image. Back: Select this item to close the submenu. Resize 1: Select an image you want to resize in playback mode. 2: Press the MENU button to display the menu. 3: Press the UP or DOWN button to select the item [Resize]. 4: Press the OK button to launch the submenu: 2048 x 1536 / 1024 x 768 / 640 x 480. 5: Press the UP or DOWN button to select the item. 6: Press the OK button to save the resized image. • The image can only be resized to smaller size.
4: Press the OK button to display the dialog box as illustration. 5: Select the item [Add] and then press the OK button to start recording voice memo. 6: Press the SHUTTER button to end the recording. • If you want to cancel the voice memo please select [Delete], when the dialog box appears, and then press the OK button to delete the memo. Set the image as the start-up image 1: Select an image you prefer in playback mode. 2: Press the MENU button to display the menu.
you selected as the start-up image. Print the image 1: Select an image you want to print in playback mode. 2: Press the MENU button to display the menu. 3: Press the UP or DOWN button to select the item [Print…]. 4: Press the OK button to enter the printing interface. 5: Connect the video camera and the printer via the attached USB cable. 6: Press OK button to start printing. 7. Connections to TV / PC Connecting the Camera to a TV Connect the video camera and the TV via the supplied cable.
2. Turn on the TV and the video camera, and then set the TV to “AV” mode. 3. When the video camera is set to record mode, you can preview the subjects you want to record on the TV screen. 4. When the video camera is set to Playback mode, you can review all the pictures, video and audio clips stored in the video camera on the TV.
and insert it into a card reader that is connected to a computer. 2:Open [My Computer] or [Windows Explorer] and double-click the removable disk icon that represents the memory card. 3: Copy images from the card into a directory of your choice on the computer’s hard disk. Connecting the Camera to a PC with the USB Cable 1: Set the USB mode to [MSDC] mode. See the details on page 24. 2: Connect the supplied USB cable to the computer's USB port and turn on the video camera.
8. Software Installation Installing the Software The bundled software CD has the drivers and software that come with video camera. Insert the CD into your CD-ROM drive. The autorun menu appears: The following software listed below will be seen on the menu of the bundled software CD on your computer screen: • Install Driver: Installs software for PC camera.
• Arcsoft Mediaimpression: Installs software for pictures and video clips. Click the items in the autorun menu to install the software. If the autorun menu does not appear automatically, open the CD-ROM in [My Computer] or [Windows Explorer] and then double-click the file named [autorun.exe] to start the program. You can also click [Run] in the Windows Startup menu, enter "D:\autorun.exe" (where D is your CD-ROM drive letter) in the text box, and click [OK]. Install Driver 1: Click [Install Driver].
“Amcap” under the folder in the program. If it is the first time you use this function, please select the item < Preview> as in the illustration. And then you can use it as the pc camera function. If you want to change the imaging size, select
9. Troubleshooting Power does not turn on. 1. Battery is inserted in the wrong direction. ★ Reload battery in the correct direction. 2. Battery is insufficient to power ★ on. battery. Replace or recharge the The camera does not take pictures. 2. Memory card is not formatted ★Insert a new memory card. ★Format the memory card again correctly. or use a new card. 1. Memory is full. Image is blurry or out of focus. 1.
camera. from other cameras. Recorded images are not saved in memory. 1. The video camera was turned ★ If the battery low indicator off before the images are appears on the LCD monitor, saved in memory. replace the battery immediately.
10. Specifications Sensor 3MegaPixels CMOS Display 2 Focus range 150cm ~ Infinity Aperture F3.2, Fixed Focus ．7" TFT Color LCD Shutter Electronic Shutter: 1/2 ~ 1/1024 sec. Resolution Still Image: 12M (4000 x 3000) / 5M (2592 x 1944) / 3M (2048 x 1536) /1M (1024 x 768) / VGA (640 x 480) Video: 720 X 480 / 640 x 480 / 320 x 240 Sensitivity Auto White balance Auto / Daylight / Tungsten / Fluorescent / Cloudy Exposure control -2EV to +2EV in 0.
Storage 32MB Internal Memory External Memory: SD / MMC / SDHC Memory Card Supported Up to 8GB TV system NTSC / PAL Power Supply AAA (alkaline/ 1.5V) Battery x 3 Ambient Operating: 0° C to 40° C temperature Storage: -20 to 60° C Microphone Built-in Speaker Built-in Dimension Camera Body: 4.43” x 2.2” x 2.13” Weight Camera Body w/o battery: 0.42 lbs Note: The product design and the specifications are subject to change without notice.
Disposal of old electrical appliances The European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the impact on human health and the environment.
