Product Documentation

2017-10-01 RB-Blu-27
T200 Thruster Specifications
Specification Table
Performance
Maximum Forward Thrust @ 16V
5.1 kgf
11.2 lbf
Maximum Reverse Thrust @ 16V
4.1 kgf
9.0 lbf
Maximum Forward Thrust @ 12V
3.55 kgf
7.8 lbf
Maximum Reverse Thrust @ 12V
3.0 kgf
6.6 lbf
Minimum Thrust
0.01 kgf
0.02 lbf
Rotational Speed
300-3800 rev/min
Electrical
Operating Voltage
6-20 volts
Max Current
25 Amps
Max Power
350 Watts
Phase Resistance
0.18 +/- 0.01 Ohms
Phase Inductance (@ 1 kHz)
0.077 +/- 0.008 mH
Physical
Length (without BlueESC)
113 mm
4.45 in
Length (with BlueESC)
131 mm
5.16 in
Diameter
100 mm
3.9 in
Weight in Air (with 1m cable)(without BlueESC)
0.76 lb
344 g
Weight in Air (with 1m cable)(with BlueESC)
0.93 lb
422 g
Weight in Water (with 1m cable)(without BlueESC)
0.34 lb
156 g
Weight in Water (with 1m cable)(with BlueESC)
0.46 lb
210 g
Propeller Diameter
76 mm
3.0 in
Mounting Hole Threads
M3 x 0.5
Mounting Hole Spacing
19 mm
0.75 in
