User's Manual

Device Specications
19
CT360
MANUAL
PAYMENT OPTIONS
MSR • Bi-directional, Triple track (Tracks 1, 2, 3)CT360
Contact Payment
• ISO 7816, 1.8V, 3V, 5V; synchronous and asynchronous cards;
EMV Level 1 and 2 type approved
Contactless Payment
• Optional,
• MasterCard PayPass M/Chip
• MasterCard PayPass MagStripe
• Visa payWave MSD
• Visa payWave qVSDC
• Pass-through access to ISO 14443-4 and MiFare/Felica cards,
for direct host terminal-based application access
• NFC(Near Field Communication), ISO18092 supported
Security • 3DES encryption, Master/Session and DUKPT key management; PCI PTS 3.1
Performance Characteristics
Processor • ARM9 32-bit, 533MHz
OS • Windows CE 6.0
Memory • 256MB (128MB of Flash, 128MB of SDRAM) standard, can exceed up to 640 MB
Interface
• One Ethernet (10/100BaseT),
one telco, two RS-232 (one optional by extention cable),
one USB 2.0 Host port and one USB Device port
Physical Characteristics
Dimension & Weight • L184 x W86 x H63 mm (7.2 x 3.3 x 2.4 inch), 410g without paper roll nor cable
Display • 320 x 240 pixel TFT LCD with LED backlighting, 2.8”
Keypad • 3 x 5 numeric backlit keypad, 4 programmable-function keys
Backup Battery & Voltage
• 7.4V / 4,440mWHr Li-ion
• AC input 100 - 240 VAC, 50/60Hz; DC Output 9V 3A
Expansion Slot • Optional, MicroSD
SIM/SAM Slot • Optional, 3 SAMs or 1 SIM / 2 SAMs
Printer
• Integrated thermal with graphics capabilities,
33 lines/second, 24 or 32 columns; standard roll paper 58mm (2.25 in.) x 40mm
Audio • Optional, Buzzer or speaker
User Environment Characteristics
Operating Temp • 0
℃
to 50
℃
/ 32
℉
to 122
℉
operating temperature
Storage Temp • -20
℃
to 60
℃
/ -4
℉
to 140
℉
Humidity • 5% to 95% relative humidity, non-condensing
Durability • Sealed keypad
Integrated Radio Options
WWAN
• Optional,
GSM/GPRS/EDGE/UMTS/HSDPA/HSPA+ or CDMA/1X/EVDO Rev0/RevA
WLAN
• Optional, IEEE 802.11 b/g/n
• WEP 64/128, WPA and TKIP, AES, CCX
WARNING
Please ask your sales representative for the specs not listed above.
