Device Specications
Payment Options
MSR • Bi-directional, Triple track (Tracks 1, 2, 3)
Contact Payment
• ISO 7816, 1.8V, 3V, 5V; synchronous and asynchronous cards;
EMV Level 1 and 2 type approved
Contactless Payment
• Optional
• MasterCard PayPass M/Chip • MasterCard PayPass MagStripe
• Visa payWave MSD • Visa payWave qVSDC
• Pass-through access to ISO 14443-4 and MiFare/Felica cards,
for direct host terminal-based application access
• NFC(Near Field Communication), ISO18092 supported
Security • 3DES encryption, Master/Session and DUKPT key management; PCI PTS 3.1
Performance Characteristics
Processor • ARM9 32-bit
OS • Windows CE 6.0
Memory • 256MB (128MB of Flash, 128MB of SDRAM) standard, can exceed up to 640 MB
Interface • Micro USB connector, DC connector, Docking connector
Physical Characteristics
Dimension & Weight • L 150 x W 78 x H 45.4 mm (5.9 x 3 x 1.7 inch), 455g without paper roll nor cable
Display • 480 x 800 pixel TFT LCD with LED backlighting, 4” capacitive touch screen
Keypad • 4 programmable-function keys
Battery & Voltage
• 7.4V / 11,100mWHr Li-ion
• AC input 100 - 240 VAC, 50/60Hz; DC Output 9V 3A
Expansion Slot • MicroSD
SIM/SAM Slot • Optional, 1 SIM / 2 SAMs
Printer
• Integrated thermal with graphics capabilities, 33lines/second,
24 or 32 columns; standard roll paper 58mm (2.25 in.) x Ø25 or 40mm
Audio • Optional speaker
User Environment Characteristics
Operating Temp • 0
℃
to 50
℃
/ 32
℉
to 122
℉
Storage Temp • -20
℃
to 60
℃
/ -4
℉
to 140
℉
Humidity • 5% to 95% relative humidity, non-condensing
Durability • 4ft. / 1.2m drop, Sealed keypad
Integrated Radio Options
WWAN
• Optional,
GSM/GPRS/EDGE/UMTS/HSDPA/HSPA+ or CDMA/1X/EVDO Rev0/RevA
WLAN
• Optional, IEEE 802.11 b/g/n
• WEP 64/128, WPA and TKIP, AES, CCX
WPAN • Bluetooth Class1
Accessories
Cradle Options
• Charger • Dial-up Modem
• Ethernet Modem • Bluetooth Class1
• RS232 up to 2 • USB Host 1, OTG 1
WARNING
Please ask your sales representative for the specs not listed above.
