Installation Guide

Note:
All Bolts to be inserted from the top side, Nuts to be
inserted from undernerath Tension straps.
End starp ; 7528 This should be used for the end.
Middle strap ; 7254, 7244, 7264 or 7285. Those should be
used for the middle.
Connect Middle strap(s) to already assembled End straps.
Using five sets of M8x20 hex head bolt and M8 nut.
Use #0106.PACK Strap Bolt Package
Use #0105.PACK Strap Bolt Package
5) CONNECTING TENSION STRAPS
6
P.No.0623
P.No.0623
M8 Nut
M8 Nut
P.No.0923
P.No.0923
M8 x 20 Hex Head Bolt
M8 x 20 Hex Head Bolt
7528 - 2pieces 33x18 - 3straps.
7264 - 2pieces
7528 - 2pieces 41x21 - 4straps.
7285 - 3pieces
7528 - 2pieces 25x15 - 2straps.
7244 - 2pieces 30x15 - 3straps.
7528 - 2pieces 16x12 - 1straps.
7254 - 1pieces 20x12 - 2straps.
24x12 - 3straps.
Quantity per set. Number of sets per pool.
12' Width Oval Pools
18' Width Oval Pools
15' Width Oval Pools
21' Width Oval Pools
Combination of Strap Set
20mm
(6120mm)
41' 1"
10'
6
"
(12520mm)
(3120mm)
5' 1/4"
(
3200mm)
2' 6-1/8"
(1530mm)(1530mm)
10' 2-7/8"
5' 1/4"
20' 1"
(765mm)
10'
6"
21'
2
5
'
5
"
(
7
7
4
7
m
m
)
(1530mm)
(6401mm)
2' 6-1/8"
41x21
(765mm)
5' 1/4"
(3200mm)
Middle strap
End strap
This end should be connected
to horizontal support.
7528 End 55-1/8" 1400
7254 Middle 32-7/8" 835
7244 Middle 36-5/8" 929
7264 Middle 55-3/8" 1405
7285 Middle 50-5/8" 1286
Parts No. Type Length(in) Length
(mm)
Length of Tension Straps.
