Installation Guide

BRACELESS OVAL PARTS LIST
Parts No. Discription
16x12x52 20x12x52 24x12x52 25x15x52 30x15x52 33x18x52 41x21x52
BL08-A or BL08-A 1/2 CARTON
5726 Horizontal Support 2464664
6254 Pressure plate L=680mm(26-3/4") 6 12 18 12 18 18 12
0109.PACK Braceless Oval Frame Bolt Package 1232334
0105.PACK Strap Bolt Package 1 2 3 2
0106.PACK Strap Bolt Package 2333
BRACELESS OVAL POOLS INSTRUCTION 1111111
5712 Side Vertical for BLE 52" 2
5617 Side Vertical Skin for 52" or 54" 2
7528 End strap L=1400mm(55-1/8") 2
7529 End strap L=1171mm 8ft
7254 Middle strap L=835mm(32-7/8") 1
7244 Middle strap L=929mm(36-5/8")
BL08-A 2/2 CARTON
5726 Horizontal Support 4
6254 Pressure plate L=680mm(26-3/4") 12
0109.PACK Braceless Oval Frame Bolt Package
5673 M14 x 30 Hex Head Bolt 24
5672 M14 Nut 24
5674 M10 x 100 Hex Head Bolt 8
5675 M10 Nut 24
0341 #12 Sheet Metal Screw 10
0105.PACK Strap Bolt Package
0623 M8 Nut 22
0923 M8 x 20 Hex Head Bolt 22
0106.PACK Strap Bolt Package
0623 M8 Nut 27
0923 M8 x 20 Hex Head Bolt 27
BL08-B or BL08-B 1/2 CARTON for 52"
5712 Side Vertical for BLE 52" 464664
5617 Side Vertical Skin for 52" or 54" 464664
7528 End strap L=1400mm(55-1/8") 464668
7254 Middle strap L=835mm(32-7/8") 2 3
7244 Middle strap L=929mm(36-5/8") 4 6
7264 Middle strap L=1405mm(55-3/8") 6
7285 Middle strap L=1287mm(50-5/8") 12
BL08-B 2/2 CARTON for 52"
5712 Side Vertical for BLE 52" 4
5617 Side Vertical Skin for 52" or 54" 4
Printed in JAPAN. Oct. 2013
11
