Owners manual

BX1698
2011-13 Chevy Cruze RS
Installation Instructions
405-0207 Rev. B Page 10 of 11 8/24/12
33. Possible location to mount the 4 or 6 pin electrical
coupler on the fascia’s lower air dam.
33

Be sure that ALL electrical connections
are plugged in properly and functioning
BEFORE installing the fascia.
Install the tow bar and safety cables according to
the instructions included in their packages. When
demonstrating this to the customer, be sure to include
all the contents and packages.
Do NOT substitute other devices if the tow bar pin and
clip are misplaced.
31. Optional: Attach the breakaway bracket to the
bottom of the bumper between two fascia ribs
with two 10-16 x 1” self drilling screws. Attach the
breakaway to the bracket with 1/4-20 x 3/4” bolt
and 1/4-20 hex nut.
31

32. Reinstall the fascia.
