PARTS LIST - INTERIOR COMPONENTS
ITEM PART NO DESCRIPTION QTY
1 DD-74427 SOLENOID SINGLE 120V 1.0 1
2 DD-73778 RETAINING CLIP TANK LID 4
3 2C-73457 NUT 8-32 HEX HEAD KEPS MS 16
4 2I-70147 GASKET TANK COVER 1
5 2K-70154 FTG UNION 1/4X1/4 1
6 2C-70155 NUT 7/16-20 HEX HD BRASS 1
7 DD-75846 TUBE INLET ASSY 9.62 1
8 2C-70512 WASHER SS .035X7/16IDX3/4OD 1
9 2U-71061 FAUCET HOT WATER 1
11 2J-72114 PROBE 8783MCD 1
12 2I-72115 GROMMET 1/4 ID TRANSLUENT 1
13 2I-72390
GROMMET .375 ID TRANSLU-
CENT
1
14 A6-72661 TUBE SIL .312 ID X 27 1
15 2K-73152 ELBOW SPRAYER 1/4 ID 2
16 TANK WELD ASSY 1
17
DD-73287 ELEM 230V 3000W 2
DD-73424UL ELEM HEATING 208V 2750W 2
18 BRACKET SOLENOID VALVE SS2 1
19 SCREW PAN SLT SS 4mm X 8mm 2
20 2I-73309 GASKET TANK HEATER SS2 1
21
DD-73572 BRKT BYPASS DOUBLE 1
N.L.A. BRKT BYPASS DELTROL 1
22 2V-73311 TUBE FILL 90DEG BEND L=22 1
23 DD-73312 THERMO HI-LIMIT DBL POLE 1
24 2P-73318 PLUG TANK LID .510 DIA 2
25 2P-73319 PLUG TANK LID .298 DIA 1
26 2P-73320 PLUG TANK LID .687 DIA 1
27 DD-73325 TANK LID WELDED ASSY SS2 1
28 D7-73314
TUBE, TANK TO VALVE, SIL .50
ID 7.3
2
29 2K-47662 FTG STR BRS 3/8NPT X 3/8IN 1
30 2O-46575 VALVE DRAIN 3/8NPT 1
31 DD-83605 ELBOW MALE 5/8 X 3/8 90 DEG 1
32 DD-73380 TUBE ASSY COPPER TUBE 1
33 DD-83381 KIT DRAIN VALVE ASSY 1
34 2C-73359 WASHER FLARE TANK DRAIN 1
35 DD-73358 PLUG TANK DRAIN SS2 1
36 DD-73357 NUT TANK DRAIN PLUG SS2 1
37 DD-73553 TUBE SIL .375 ID X 72” 1
38 2K-70103 ELBOW OUTLET 2
ITEM PART NO DESCRIPTION QTY
39 2A-73384 TUBE SPRAY HEAD 2 3/8” LG 2
40 A6-73537 TUBE SIL .312 ID X 9” LG 3
41 2V-73388 VALVE ADJUST WATER OUTLET 2
42 D7-70699
TUBE INLET HOSE, SIL .375 ID
X 17.25
1
43 BRACKET BYPASS VALVE 2
44 2C-72148 WASHER LOCK 1/2 ID INT SE 1
45 SCREW 10-32 X 1/2 PH PAN 4
46 2C-35485 NUT 1/4-20 HEX FINISHED 1
48 DD-76934 FTG ELBOW W/EXTENSION 2
49 F4-70409 WASHER BEVELLED 2
50 2I-70152 GASKET ELEM HTG 2
51 2C-73147 WASHER GYLON 1/2 ID 3/4 OD 2
52 2C-72739 NUT TANK FITTING #304 3/4 2
53 2J-73313 PROBE THERMISTOR PASSSIVAT 1
54 D7-73414 SHIELD HI-LIMIT 1
55 2C-73415 NUT 6-32 HEX 1.00 LG ALUM 2
56 2V-70111 TUBE FORMED INLET ASSY 1
57 2V-73027 STRAINER ‘Y’ PLASTIC W/FT 1
58 DD-73571 INSERT SPRAY HEAD SS2 2
59
WS-83617 VALVE SOL BYPASS ASSY 120V 2
2V-72729 VALVE ADJUST DISPENSING 1
2I-73570 INSERT BYPASS REG SS2 1
A6-73537 TUBE SIL .312 ID X 9 LG 1
WS-83618 VALVE SOL DISP ASSY 120V 2
2V-73388 VALVE ADJUST WATER OUTLET 1
2I-73570 INSERT BYPASS REG SS2 1
A6-73537 TUBE SIL .312 ID X 9” LG 1
60 2C-70379 SCREW 8-32X5/16 PH PAN MS 6
61 WASHER FLAT SS #8 2
62 2C-70405 SCREW 6-32X1/4 RD HD M 2
63 DD-74063 GROMMET .510 OD X 250 ID 1
64 2C-72681 WASHER FLT 15/32X1 1/8 1
65 RETAINING TUBE 1
66 BOTTOM PLATE TUBE RETAINER 1
67 DD-74434 TUBE FORMED SS 1
68 DD-74433 TUBE SIL .312 X 6” 1
69 DD-74435 INSUL LYTHERM FAUCET TUBE 1
70 DD-74650 TUBE SIL .312 ID 4.8L 1
DD-74345-M672 OP MANUAL DUAL SATELLITE BREWERS DD-74345-M672 OP MANUAL DUAL SATELLITE BREWERS
