PARTS LIST - CABINET AND EXTERIOR COMPONENTS
ITEM PART NO DESCRIPTION QTY
1 COVER TOP HOUSING SS2 1
2 TOP HOUSING WLD ASSY SS2 1
3 BODY WLD ASSY SS2 1
4 BASE WLD ASSY SDS-2 1
5 BTM PLATE WLD ASSY 1
6 PANEL BACK SS2 1
7 PANEL FRONT SS2 1
8
BRACKET CONTROL BOARD MTG
SS2
1
9 BRACKET TANK SUPPORT TOP SS2 2
10 2K-70229 BUSHING SHORTY HEYCO 3
11 D7-72738 SPOUT ASSY 2
12 2E-73046 CONNECTOR WIRED ASSY SDS- 2
13 DD-73077 HANDLE GUIDE L 3
14 2A-73098 LEG 4” BLK PLASTIC W/FLANGE 4
15 2A-73107 FEET RUBBER BLACK 4
16 2K-300102 STRAIN RELIEF 1NPT .375-1 1
17 DD-37512 PLUG HOLE 1 3/8” 1
18 SCREW, PAN, NI #8-32 X 1/4 4
19
2I-70139 GASKET SPRAY HEAD
2
2I-72215 GASKET SPRAY HEAD 1.5 ID
20 A6-72727 SPRAY HEAD DISC EMBOSSED 2
21 2E-40310 TERM BLOCK 4POLE 75AMP 1
22 DD-71265 FUSEHOLDER 1
23 DD-71266 FUSE 5A 1
24 DD-74323 POWER & CONTROL BOARD ASSY 1
25 DD-75239 KEYPAD SS2 1
26 BRACKET HEAT SINK SS2 2
27 2C-70379 SCREW 8-32X5/16 PH PAN MS 56
28 2C-48748 SCREW 4-40X3/8 PH PAN #F 4
29 2C-73457 NUT 8-32 HEX HEAD KEPS MS 25
30 2C-31243 SCREW 8-32X7/8 PH RD HD 4
31 2A-73362 SPACER .375 OD, .25L 4
32 DD-70049 SCREW 8-32X1/2 PH PAN HD 2
33 WASHER #8 EXT SEMS 6
34 2C-35313 NUT 10-32 HEX MS SS 1
35 2E-73392 HEAT SINK & TRIAC ASSY 1
ITEM PART NO. DESCRIPTION QTY
36
37 2E-72936 SWITCH ROCKEER ON-OFF .125 1
38 2E-37780 CONTACTOR 3P, 240V, 40A ALT3 1
39 2E-73552 WIRE ASSY WATER LEVEL PRO 1
40 LUG GROUND SOLDERLESS 6-14G 1
41 2B-70466 RACK WIRE BREW CHAMBER 2
42 2C-70115 SCREW 10-32X5/16 HEX HD M 2
43 2C-70467 CLIP BREW BASKET 2
44 2D-73101 CHAMBER BREW .187 HOLD NO 2
45 2R-70112 HANDLE BLACK 2
46 A6-73100 BREW CHAMBER ASSY SS1 .18 2
47 DD-73885 SHIELD DRIP CONTACTOR 1
48 WASHER, FLAT #4 .312 OD 2
49
50 A6-70888 DOOR ACCESS SOLENOID 1
51 DD-75235 PLUG BUTTON 1/2 DIA BLK 1
