4. OPERATING ADJUSTMENTS

The Control Panel

All the goodies and different modes possible with the SnowBlind™ are accessed

byusingthecontrolpanelonthesideofthexture.Thereare4control

buttonsbelowtheLEDdisplaywhichallowyoutonavigatethroughthevarious

control panel menus.

<MODE>

Is used to navigate the various modes.

<SETUP>

Is used to enter into the selected mode setup.

<UP>

Scrolls through menu items and numbers in ascending order.

<DOWN>

Scrolls through menu items and numbers in descending order.

TheControlPanelLEDDisplayshowsthemenuitemslistedontheControl

Panel Menu Structure below. Pushing the <MODE> button repeatedly will

scroll through the menu settings. To edit one, push the <SETUP> button.

Then use the <UP> and <DOWN> buttons to scroll through your choices (if

applicable).Pushthemodebuttontoconrmyourchoice.

Control Panel Menu Structure

CON 000 - 255 Brightness Control (Low <--> High)

F.00 - F.30 Sets the Strobe Speed (Slow <--> Fast)

SE- SE.0 - SE.9 Sound Active, Mic Sensitivity (0-9, 0=off)

*Note: The rear sensitivity knob must be turned up (clockwise) for the control panel settings will function.

Also, for the knob to function, the menu settings must not be set to off (SE.0).

SLA Sets Fixture to Slave Mode

d-- 001 - 255 Selects the Starting DMX Channel

Mode Setup doWNup
