Instruction Manual

Page 5
SnowBank User Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
2. MEET THE SNOWBANK™ LED BLINDER
MAIN FEATURES:
•Userselectable7or26DMXchannels
•Poweredby32Tri-ColorRGBLED’s
•Fullcolormixinginstandalone,master/slaveandDMXmodes
•Built-inautomatedprogramsviamaster/slave
•Built-insoundactivatedprogramsviamaster/slave
•EasytouseLEDdigitalcontrolpanel
•3-pinmaleinputand3-pinfemaleoutput
•Dualmountingyokeallowsexibilityinpositioning
•Heavyduty,blackaluminumhousing
OPTICAL:
•BeamAngle:45°
•400hzicker-freeLEDdrivers
•LightSource:32*3-wattTri-ColorLEDs,100,000hours
CONTROL:
•USITTDMX-512(26/7Channels)
•3-pinInput/Output
•LED4-buttoncontrolpanel
DMX Quick Reference (26-Channel Mode)
Channel Channel
1 Dimmer
2-25 Individual Pixel R/G/B Intensity
26 Strobe
DMX Quick Reference (7-Channel Mode)
Channel Channel
1 Dimmer
2 Global Red Intensity
3 Global Green Intensity
4 Global Blue Intensity
5 Built-in Programs
6 Speed
7 Strobe
