Blizzard Lighting, LLC www.blizzardlighting.
TABLE OF CONTENTS SnowBank™ 1 1. Getting Started 3 What’s In The Box? Getting It Out Of The Box Powering Up! Getting A Hold Of Us Safety Instructions (Don’t Stick Your Hand In The Toaster!) 3 3 3 3 4 2. Meet The SnowBank™ 5 Features DMX Quick Reference The SnowBank™ Pin-up Picture 5 5 6 3.
1. GETTING STARTED What’s In The Box? • 1 x SnowBank™ Professional LED Fixture • This Lovely User Manual Getting It Out Of The Box Congratulations on purchasing one of the coolest LED fixtures anywhere! Now that you’re the proud owner of a SnowBank™ (or hopefully, MORE!), you should carefully unpack the box and check the contents to ensure that all parts are present and in good condition.
SAFETY INSTRUCTIONS • Please keep this User Guide for future use. If you sell the unit to someone else, be sure that they also receive this User Guide. • ALWAYS make sure that you are connecting to the proper voltage, and that the line voltage you are connecting to is not higher than that stated on the decal or rear panel of the fixture. • This product is intended for indoor use only. • To prevent risk of fire or shock, do not expose fixture to rain or moisture.
2.
Figure 1: The SnowBank™ Pin-Up Picture Black Aluminum Casing High Power Tri-Color LEDs Locking Knobs Dual Mounting Brackets Figure 2: The Rear Connections DMX In DMX Out AC Power In SnowBank User Manual Rev.
3. SETUP Fuse Replacement CAUTION! The SnowBank™ utilizes a high-output switch-mode power supply with an internal fuse. Under normal operating conditions, the fuse should not require replacement. The fuse is field replaceable, however it is an advanced procedure suited to qualified individuals. Should your SnowBank™ fuse require replacement, please contact Blizzard Lighting for instructions, or to return your unit for service.
Cable Connectors Cables must have a male XLR connector on one end and a female XLR connector on the other end. (Duh!) CAUTION: Do not allow contact between the common and the fixture’s chassis ground. Grounding the common can cause a ground loop, and your fixture may perform erratically. Test cables with an ohm meter to verify correct polarity and to make sure the pins are not grounded or shorted to the shield or each other.
Fixture Linking (Master/Slave Mode) 1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the first fixture. 2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin connector to the input connector of the next fixture consisting of a (male) 3 pin connector. Then, proceed to connect from the output as stated above to the input of the following fixture and so on.
4. OPERATING ADJUSTMENTS The Control Panel All the goodies and different modes possible with the SnowBlind™ are accessed by using the control panel on the side of the fixture. There are 4 control buttons below the LED display which allow you to navigate through the various control panel menus. Mode Setup UP DOWN Is used to navigate the various modes. Is used to enter into the selected mode setup. Scrolls through menu items and numbers in ascending order.
Control Panel Menu Structure d001 d001 - d512 To choose the DMX address 7-CH To choose 7 channel DMX mode 26CH To choose 26 channel DMX mode SLAu Sets the fixture to run in slave mode SU-- SU00-SU31 Built-in sound active effects Colr r000-r255 Red color adjustment (0% <--> 100%) 9000-9255 Green color adjustment (0% <--> 100%) b000-b255 Blue color adjustment (0% <--> 100%) Pr-- Pr01 - Pr22 Built-in programs AU7O SP01 - SPFL Speed adjustment (slow <--> fast)
DMX Mode Allows the unit to be controlled by any universal DMX controller. 1.) The default mode for the fixture is DMX, which appears as d001 on the LED Readout. To select a different DMX address, hit the button and use the buttons to select the correct address, then hit again to confirm. Auto, Master/Slave, Sound Active Modes: Allows a single or Master/Slaved units to run factory installed programs at user selectable speeds. 1.
DMX Values In-Depth (26-Channel Mode) Channel Value What It Does 1 000 <--> 255 Dimmer (0% <--> 100%) 2 000 <--> 255 Pixel 1 Red Intensity (0% <--> 100%) 3 000 <--> 255 Pixel 1 Green Intensity (0% <--> 100%) 4 000 <--> 255 Pixel 1 Blue Intensity (0% <--> 100%) 5 000 <--> 255 Pixel 2 Red Intensity (0% <--> 100%) 6 000 <--> 255 Pixel 2 Green Intensity (0% <--> 100%) 7 000 <--> 255 Pixel 2 Blue Intensity (0% <--> 100%) 8 000 <--> 255 Pixel 3 Red Intensity (0% <--> 100%) 9 000 <--> 2
DMX Values In-Depth (7-Channel Mode) Channel Value What It Does 1 000 <--> 255 Dimmer (0% <--> 100%) 2 000 <--> 255 Global Red Intensity 3 000 <--> 255 Global Green Intensity 4 000 <--> 255 Global Blue Intensity 5 000 008 016 024 032 040 048 056 064 072 080 088 096 104 112 120 128 136 144 152 160 168 176 184 192 200 208 216 224 232 No Function Red Yellow Green Cyan Blue Purple White Program 1 Program 2 Program 3 Program 4 Program 5 Program 6 Program 7 Program 8 Program 9 Program 10 Program
5. APPENDIX A Quick Lesson On DMX DMX covers (and is an abbreviation for) Digital MultipleXed signals. It is the most common communications standard used by lighting and related stage equipment. DMX provides up to 512 control “channels” per data link. Each of these channels was originally intended to control lamp dimmer levels. You can think of it as 512 faders on a lighting console, connected to 512 light bulbs.
Keeping Your SnowBank™ As Good As New The fixture you’ve received is a rugged, tough piece of pro lighting equipment, and as long as you take care of it, it will take care of you. That said, like anything, you’ll need to take care of it if you want it to operate as designed. You should absolutely keep the fixture clean, especially if you are using it in an environment with a lot of dust, fog, haze, wild animals, wild teenagers or spilled drinks.
Tech Specs! Weight & Dimensions Length 19.7 inches (50 cm) Width 6.7 inches (17 cm) Height 13.4 inches (34 cm) Weight 12 pounds (5.5 kg) Power Operating Voltage AC 100/240VAC, 50-60 Hertz Power Consumption 110W Light Source LED 32* 3-watt Tri-Color LEDs, 100,000 hours Optical Beam Angle 45 degree optics standard Thermal Max. Operating Temp.
This page intentionally left blank. SnowBank User Manual Rev.
This page intentionally left blank.
Enjoy your product! Our sincerest thanks for your purchase! --The team @ Blizzard Lighting
