Puck Couch Potato RGB Manual Rev. B Copyright (c) 2013 Blizzard Lighting, LLC
2. MEET THE PUCK RGB: COUCH POTATO
CONTROL FEATURES
•RGBcolormixingvia14410mmR/G/BLEDs
•IRremotecontrolfunctionality
•Variableelectronicstrobe
•Variableelectronicdimmer
•Built-inautomatedprogramsviaDMXandmaster/slave
•Built-insoundactiveprograms
•FullRGBcolormixinginstandaloneandmaster/slave
•RGB(3-Channel)andextended(6-Channel)DMXmodes
ADDITIONAL FEATURES
•LightweightandCompact(ItkeptitsNewYears’resolution!)
•4-ButtonLEDcontrolpanelforeasyprogramming
•Lightsource:144x10mmLEDs,48eachR/G/B
•Dualbracketforexibilityinmounting
•Poweroutletforxturelinking(upto50xtures)
DMX Quick Reference (6-Channel Mode)
Channel What It Does
1 Red Intensity
2 Green Intensity
3 Blue Intensity
4 Built-in Programs
5
Strobe (0-15 off, 16-255 strobe
slow <-> fast)
6 Dimmer
DMX Quick Reference (3-Channel Mode)
Channel What It Does
1 Red Intensity
2 Green Intensity
3 Blue Intensity
