2. MEET THE ToughPAR™ Quadra LED PAR

CONTROL FEATURES

• Astounding RGBW color mixing via 18x 10W Red/Green/Blue/White

“4-in-1” LEDs

• Variable electronic strobe & dimmer w/32-bit dimming

• Built-in color & chase macros via DMX

• Built-in automated programs via master/slave

• Built-in sound active programs

• RGBW color mixing ability in standalone mode

• HSV (3-Ch), RGBW (4-Ch), RGBW + Dimmer (5-Ch) & Extended (8-

Ch) DMX Proﬁ les

• 5 user-selectable 32-bit dimming curves

ADDITIONAL FEATURES

• Tough-As-Nails IP65-rated enclosure.

• Light source: 18x 10-watt 4-in-1 LEDs

• Totally silent convection cooling

• Dual mounting brackets for positioning ﬂ exibility

• Flicker-free constant-current LED driver

DMX Quick Reference - 8 / 9 Channel Mode

Channel 8 Channel 9 Channel

1 Dimmer Dimmer

2 Red Intensity Red Intensity

3 Green Intensity Green Intensity

4 Blue Intensity Blue Intensity

5 White Intensity White Intensity

6 Strobe Strobe

7 Built-in Programs Built-in Programs

8 Program Speed Program Speed

9 --- 32-Bit Dimmer

DMX Quick Reference - 3 (HSV) / 4 / 5 Channel Mode

Channel HSV 4 Channel 5 Channel

1 Hue Red Intensity Red Intensity

2 Saturation Green Intensity Green Intensity

3 Value Blue Intensity Blue Intensity

4 --- White Intensity White Intensity

5 --- --- Dimmer
