FURY Manual Rev. A Copyright (c) 2010 Blizzard Lighting, LLC
2. MEET THE FURY™ SPOT
CONTROL FEATURES
7 or 11-channel DMX LED moving yoke•
Pan: 540º / Tilt: 270º •
Color wheel: 7 colors + white, Split Colors•
Rainbow color spin at variable speeds•
7 gobos + open (2 glass, 5 metal)•
Gobo wheel spin at variable speeds•
Variable electronic strobe•
Variable electronic dimmer (0 – 100%)•
Built-in automated programs•
Built-in sound activated programs•
ADDITIONAL FEATURES
1 High-powered, 30 W (12,500 mA) LED•
User-selectable pan/tilt ranges•
Reset to factory settings option•
User-selectable basic or advanced operating modes•
DMX Quick Reference (11-Channel Mode)
Channel What It Does
1Pan
2 Pan Fine (16-Bit)
3 Tilt
4 Tilt Fine (16-Bit)
5 Pan/Tilt Speed
6 Strobe
7 Dimmer
8 Color
9 Gobo
10 Focus
11 Built-In Programs
Page 6
FURY Manual Rev. A Copyright (c) 2010 Blizzard Lighting, LLC
DMX Quick Reference (7-Channel Mode)
Channel What It Does
1Pan
2 Tilt
3 Strobe
4 Dimmer
5 Color
6 Gobo
7 Dimmer
Figure 1: The FURY Pin-Up Picture
Lens
Control Panel
LED
Readout
Head
Figure 2: The Rear Connections
Power
Fuse Cover
DMX In DMX Out
