Manual

Page 19
FURY Manual Rev. A Copyright (c) 2010 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Length 8.25 inches (210 mm)
Width 8.25 inches (210 mm)
Height 10.75 inches (324 mm)
Weight 12.6 lbs (5.75 kg)
Power
Operating Voltage 110/230VAC 50/60Hz (Switchable)
Fuse 1A 250V (fast-blow)
Power Consumption 90W @ 120V
Light Source
LED 1x30W 12,500mA LED 50,000 hours
Optical
Beam Angle 13 degrees
Luminous Intensity 6,300 (full white) lux/1m
Movement Range
Pan 530 degrees
Tilt 270 degrees
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol USITT DMX-512
DMX Channels 9 or 12 (User Selectable)
Input 3-pin XLR Male
Output 3-pin XLR Female
Coolness Factor
Leventy Billion Percent
Warranty
2-year limited warranty, does not cover mal-
function caused by damage to LED’s.
Enjoy your product!
Our sincerest thanks for your purchase!
--The team @ Blizzard Lighting
