Blizzard Lighting, LLC

www.blizzardlighting.com

Brookﬁ eld, WI USA

Page 2

TABLE OF CONTENTS

FURY™ 30W LED Moving Head Spot 1

1. Getting Started 3

What’s In The Box? 3

Getting It Out Of The Box 3

Powering Up! 3

Getting A Hold Of Us 3

Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4

2. Meet The FURY™ Spot 5

Features 5

DMX Quick Reference (11-Channel Mode) 5

DMX Quick Reference (7-Channel Mode) 6

The FURY Pin-up Picture 6

3. Setup 7

Fuse Replacement 7

Connecting A Bunch Of FURYs™ 7

Data/DMX Cables 7

Cable Connectors 8

3-Pin??? 5-Pin??? Huh? 8

Take It To The Next Level: Setting up DMX Control 8

Fixture Linking (Master/Slave Mode) 9

Mounting/Rigging 9

4. Operating Adjustments 10

The Control Panel 10

Control Panel Menu Structure 11

Additional User Adjustments 12

Setting the pan/tilt/Menu to inverting or non-inverting 12

Setting the DMX channel conﬁ guration 12

Setting the maximum pan angle 12

Setting the maximum tilt angle 12

Service Functions 12

Resetting the ﬁ xture 12

Restoring Factory Defaults 12

Stand-Alone (“Auto”) Mode 13

Master/Slave (“Auto” or “Sound Active”) 13

DMX Mode 13

DMX Channel Values In-Depth (11-Channel Mode) 14

DMX Channel Values In-Depth (7-Channel Mode) 15

Troubleshooting 16

5. Appendix 17

A Quick DMX Lesson 17

Keeping Your FURY Spot As Good As New 18

Returns (Gasp!) 18

Shipping Issues 18

Tech Specs 19

Summary of content (10 pages)

PAGE 1
TABLE OF CONTENTS FURY™ 30W LED Moving Head Spot 1 1. Getting Started 3 What’s In The Box? Getting It Out Of The Box Powering Up! Getting A Hold Of Us Safety Instructions (Don’t Stick Your Hand In The Toaster!) 2. Meet The FURY™ Spot 5 Features DMX Quick Reference (11-Channel Mode) DMX Quick Reference (7-Channel Mode) The FURY Pin-up Picture 5 5 6 6 3.
PAGE 2
1. GETTING STARTED SAFETY INSTRUCTIONS What’s In The Box? • • • • • 1 x FURY™ Spot An Ever-So-Handy Power Cord A Handy DMX cable A Totally Useful Set of Mounting Brackets This Lovely User Manual • Please keep this User Guide for future use. If you sell the unit to someone else, be sure that they also receive this User Guide.
PAGE 3
2.
PAGE 4
3. SETUP Cable Connectors Cables must have a male XLR connector on one end and a female XLR connector on the other end. (Duh!) Fuse Replacement With a flat head screwdriver, wedge the fuse holder out of its housing. Remove the damaged fuse from its holder and replace with exact same type fuse. Insert the fuse holder back in its place and reconnect power.
PAGE 5
Fixture Linking (Master/Slave Mode) 1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the first fixture. 2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin connector to the input connector of the next fixture consisting of a (male) 3 pin connector. Then, proceed to connect from the output as stated above to the input of the following fixture and so on.
PAGE 6
Control Panel Menu Structure Additional User Adjustments TO SET THE PAN TO REVERSED OR NORMAL: 1.) Press the button until it shows or 2.) Use the buttons to set to the desired position, press to confirm. TO SET THE TILT TO REVERSED OR NORMAL: or 1.) Press the button until it shows 2.) Use the buttons to set to the desired position, press to confirm. TO SET THE LED READOUT TO REVERSED OR NORMAL: 1.
PAGE 7
Stand-Alone Mode (Auto Mode): DMX Channel Values (11 Channel Mode) Allows a single unit to run to a factory installed program at one of two speeds. 1.) To set the fixture in auto mode fast, select Once confirmed the display reads . . 2.) To set the fixture in auto mode Slow, select . . Once confirmed the display reads Master/Slave Mode (Auto or Sound Active): Channel Channel Value Does...
PAGE 8
DMX Channel Values (7 Channel Mode) Channel Channel Value Does...
PAGE 9
5. APPENDIX Keeping Your FURY As Good As New A Quick Lesson On DMX DMX (aka DMX-512) was created in 1986 by the United States Institute for Theatre Technology (USITT) as a standardized method for connecting lighting consoles to lighting dimmer modules. It was revised in 1990 and again in 2000 to allow more flexibility. The Entertainment Services and Technology Association (ESTA) has since assumed control over the DMX512 standard. It has also been approved and recognized for ANSI standard classification.
PAGE 10
Tech Specs! Weight & Dimensions Length 8.25 inches (210 mm) Width 8.25 inches (210 mm) Height 10.75 inches (324 mm) Weight 12.6 lbs (5.75 kg) Power Operating Voltage 110/230VAC 50/60Hz (Switchable) Fuse 1A 250V (fast-blow) Power Consumption 90W @ 120V Light Source LED 1x30W 12,500mA LED 50,000 hours Optical Beam Angle 13 degrees Luminous Intensity 6,300 (full white) lux/1m Movement Range Pan 530 degrees Tilt 270 degrees Thermal Max. Operating Temp.
