Tech Specs!
Weight & Dimensions
Width 6.81 inches (173 mm)
Depth 6.81 inches (173 mm)
Height 12 inches (305.8 mm)
Weight 9.3 lbs (4.5 kg)
Power
Operating Voltage 100-240VAC, 50-60 Hertz
Power Consumption 40W, .57A, pf:.62
Light Source
LED 9x 15W 6-in-1 LEDs 100,000 hours.
Optical
Beam Angle 25 degree optics standard
26 degree beam
30 degree eld
Luminous Intensity
(Top LEDs)
Lux/m Red Green Blue Amber White All
1m 1405 1788 2000 1087 3230 3510
2m 380 462 498 262 692 1000
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol USITT DMX-512
DMX Channels 6 / 11 / 15 / 18
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating Modes
Standalone, Master/Slave, Sound Active, Color
Preset
Other Information
It is hard to eat angrily.
Warranty
2-year limited warranty, does not cover mal
-
function caused by damage to LED’s.
DISCLAIMER:
The power connector tted to the xture and xture cord are designed for compatibility
with products manufactured by Neutrik AG, Neutrik USA and their related entities, however
they are not manufactured by, afliated with or endorsed by Neutrik AG, Neutrik USA, or
any related entity. Neutrik® and powerCON® are registered trademarks of Neutrik AG.
