(18-Channel Mode, Continued)
Ch. Value What It Does
14 000 <--> 010
011 <--> 255
No Function
Layer 1 Strobe Speed (slow <--> fast)
15 000 <--> 010
011 <--> 255
No Function
Layer 2 Strobe Speed (slow <--> fast)
16
Value What It Does Value What It Does Value What It Does
001 <--> 015
016 <--> 018
019 <--> 021
022 <--> 024
025 <--> 027
028 <--> 030
031 <--> 033
034 <--> 036
037 <--> 039
040 <--> 042
043 <--> 045
046 <--> 048
049 <--> 051
052 <--> 054
055 <--> 057
058 <--> 060
061 <--> 063
064 <--> 066
067 <--> 069
070 <--> 072
073 <--> 075
076 <--> 078
Dimming
R
G
B
A
W
UV
R+G
R+B
R+A
R+W
R+UV
G+B
G+A
G+W
G+UV
B+A
B+W
B+UV
A+W
A+UV
W+UV
079 <--> 081
082 <--> 084
085 <--> 087
088 <--> 090
091 <--> 093
094 <--> 096
097 <--> 099
100 <--> 102
103 <--> 105
106 <--> 108
109 <--> 111
112 <--> 114
115 <--> 117
118 <--> 120
121 <--> 123
124 <--> 126
127 <--> 129
130 <--> 132
133 <--> 135
136 <--> 138
139 <--> 141
142 <--> 144
R+G+B
R+G+A
R+G+W
R+G+UV
R+B+A
R+B+W
R+B+UV
R+A+W
R+A+UV
R+W +UV
G+B+A
G+B+W
G+B+UV
G+A+W
G+A+UV
G+W+UV
B+A+W
B+A+UV
B+W+UV
A+W+UV
R+G+B+A
R+G+B+W
145 <--> 147
148 <--> 150
151 <--> 153
154 <--> 156
157 <--> 159
160 <--> 162
163 <--> 165
166 <--> 168
169 <--> 171
172 <--> 174
175 <--> 177
178 <--> 180
181 <--> 183
184 <--> 186
187 <--> 189
190 <--> 192
193 <--> 195
196 <--> 198
199 <--> 201
202 <--> 204
205 <--> 229
230 <--> 255
R+G+B+UV
R+G+A+W
R+G+A+UV
R+G+W+UV
R+B+A+W
R+B+A+UV
R+B+W+UV
R+A+W+UV
G+B+A+W
G+B+A+UV
G+B+W+UV
G+A+W+UV
B+A+W+UV
R+G+B+A+W
R+G+B+A+UV
R+G+B+W+UV
R+G+A+W+UV
R+B+A+W+UV
G+B+A+W+UV
Full ON
Auto Snap
Auto Fade
17 000 <--> 015
016 <--> 255
No Function
Color Fade (slow <--> fast)
18
000 <--> 005
006 <--> 055
056 <--> 105
106 <--> 155
156 <--> 205
206 <--> 255
32-Bit Dimmer
As set in the control menu display
Mode 0 = 8-bit, 256 dimming steps
Mode 1 = 32-bit, 0-25% intensity range
Mode 2 = 32-bit, 0-50% intensity range
Mode 3 = 32-bit, 0-75% intensity range
Mode 4 = 32-bit, full intensity dimming
Troubleshooting
Symptom Solution
Fixture Auto-Shut
Off
Check the fan in the xture. If it is stopped or moving slower than normal,
the unit may have shut itself off due to high heat. This is to protect the xture
from overheating. Clear the fan of obstructions, or return the unit for service.
No Light Output Check to ensure xture is operating under correct mode, IE sound active/auto/
DMX/Etc., if applicable.
Chase Speed Too
Fast/Slow
Check to ensure proper setup of speed adjustment.
No Power Check fuse, AC cord and circuit for malfunction.
No Response to
Audio
Verify that the xture is in “Sound Active” mode.
Adjust Audio Sensitivity, If Applicable.
Fixture Not Respond-
ing / Responding
Erratically
Make sure all connectors are seated properly and securely.
Use Only DMX Cables and/or check cables for defects
Install a Terminator.
Reset xture(s).
