Instruction Manual

WARNING: All images and text in this manual is the property of Blitz Co., Ltd. (Japan).

No parts of this manual may be reproduced, stored in retrieval systems, or transmitted in any way

without prior written permission of Blitz Co., Ltd. (Japan).

1. Com

resso

3. Intake Manifold

9. Compressor

Stay

⑦Flange Bolt

③

Flan

e Bolt

⑭Flange Nut

⑰Stud Bolt

1. Compressor

3. Intake Manifold

13) Install five ⑯ Stud Bolts at the circled

locations.

)

Install the 3.Intake Manifold to

the1.Compressor using the 5.Compressor

Gasket; 9.Compressor Stay; ① Flange

bolt(1P); ③Flange Bolt (1P);⑦Flange Bolt

(1P); ⑫Flange Nuts (5P) and ⑭Flange Nut

(1P).

※ Use the ⑫Flange Nuts to tighten the ⑯

Stud Bolts. Use one ①Flange Bolt to

tighten the last hole.

15) Install ⑰three Stud Bolts to the surface of

the engine’s intake manifold.
