(20)Installation of the A/C pipe stay.

① Remove the bolt

(

one bolt

)

from the

genuine A/C pipe stay.

Genuine

A/C Pipe

② Relocate the A/C pipe stay to the

location shown in the diagram.

③ Install the (C. 45) φ 9 hose cut to

30mm between the genuine A/C pipe

and the genuine A/C pipe stay.

※Cut the hose to install around the

A/C pipe.

④ Install the (C. 15) A/C pipe stay in

between where the genuine A/C pipe

stay is located, and use the

(

C. b

)

flange

bolt M6 X 16

(

)

(

M. o

)

flange nut M6

(

)

and the genuine A/C pipe stay

bolt.

※Ad

ust the A/C hose to not get in

contact with the

(

C. 1

)

compressor and

the compressor pulley.

Genuine

A/C pipe stay

(C. 15) A/C Pipe

Stay

(C. 45) φ9 Hose

(C. b) Bolt

(C. o) Nut

Genuine

Bolt

（21）Install the (C. 48) colgate tube cut to

100mm around the A/c hose where it

gets into contact with the

(

C. 1

)

compressor inlet chamber.

Contacti

location

(C. 48) φ 19 Colgate
