Item Brochure

7
Construction Specifications
Standard
Dimensions
All Freestanding Cabinets: 16” deep
Materials 304 stainless steel
1
/
4
” clear tempered sheet glass
Gauge Body, Sloped Top, Drawers, and Shelf Inserts: 18GA; Legs: 12GA
Glass Doors (Front and Back): 18GA
Solid Doors (Front): 18GA; Solid Doors (Back): 20GA
Welding All welding by heliarc method and exposed welds are ground smooth
Finish Exposed surfaces are free from pit marks, weld seams, scale and are
polished with #4 polish to a satin finish
Casters 2” or 3” ball bearing, swivel casters with brakes
Notes • Kay: A counter weight is fastened underneath at bottom rear of cabinet
for doors in open position. Upper door fitted with lock handle and three
way latching device engaging at top.
• Kennedy: Right hand door equipped with a locking knob and three
way latching. Left hand door with dummy knob and roller latch. An inde-
pendently locked narcotic cabinet, 13
1
/
4
” x 5” x 7
3
/
4
” with double walled
door is welded to the bottom, back, and side of the compartment.
• Paul & Walter: A counter weight is fastened underneath at bottom rear
of cabinet for doors in open position. Right hand door is fitted with a lock-
ing handle and three point latching, and the left door has a dummy knob
and spring loaded nylon roller catches.
Cabinets
FREESTANDING
Construction
Specifications
Shipping Information
All shipping weights are estimates and may be changed without prior notice. Specifications
may be improved and dimensions changed without prior notice. Please contact customer
service for estimated shipping costs at [e-mail].
