Item Brochure

23
Construction Specifications
Standard
Dimensions
All console cabinets are 16” high x 18” deep, widths vary
Exception: warming cabinets are 20” deep
Materials 304 Stainless Steel
1/4” clear tempered sheet glass
Gauge Body, Sloped Top, Drawers, and Shelf Inserts: 18GA
Glass Doors: Front and Back: 18GA
Solid Doors (Front): 18GA; Solid Doors (Back): 20GA
Welding All welding by heliarc method and exposed welds are ground smooth
Finish Exposed surfaces are free from pit marks, weld seams, scale and are
polished with #4 polish to a satin finish
Casters N/A
Notes
• All Console Cabinets: Solid doors are double panned, channel reinforced. Glass
doors come in double shell design, with one piece outer frames dieformed to
receive rubber gasketed glass panels held in place by inner retaining strips.
• Double Door Console Cabinets: Right door fitted with two point up and down knob
latching, left hand door with integral stops, dummy knob, and spring loaded nylon
roller catch. Doors operate on three semi-concealed stainless steel hinges.
Pegboard Cabinet interiors (back and sides) are lined with removable 18GA
stainless steel pegboard.
• Desk Console Cabinet: Four drawers with double wall fronts operate on side mounted,
two section ball bearing roller slides with built-in extension stops. Heads provided
with diecast aluminum bar pulls.
• Single Door Shelving Console Cabinet: Can be either right or left hinged.
• Recessed Warming Cabinet: Temperature control from 90°F - 160°F. 160x180 pixel
graphical display with dual colors (red/green). Built-in temperature data recorder
with real time clock (RTC).
Cabinets
CONSOLE CABINET
Construction
Specifications
Shipping Information
All shipping weights are estimates and may be changed without prior notice. Specifications
may be improved and dimensions changed without prior notice. Please contact customer
service for estimated shipping costs at [e-mail].
