Construction Specifications
Standard
Dimensions
High Cabinets: 84” tall x 18” deep, widths vary
Wall Cabinets: 30” tall x 13” deep, widths vary
Base Cabinets: 35
3
/
4
” tall x 22” deep, widths vary
Countertops: 1” overhang in front and both sides of base cabinets
Materials 304 Stainless Steel
1/4” clear tempered sheet glass
Gauge Body, Sloped Top, Drawers, and Shelf Inserts: 18GA; Base: 16GA
Glass Doors (Front and Back): 18GA
Solid Doors (Front): 18GA; Solid Doors (Back): 20GA
Welding All welding by heliarc method and exposed welds are ground smooth
Finish Exposed surfaces are free from pit marks, weld seams, scale and are
polished with #4 polish to a satin finish
Casters N/A
Notes
• Cabinet Parts:
d Hinge Doors: Hung on semi concealed stainless steel hinges and fitted with die cast
aluminum bar pulls and spring loaded nylon roller catches.
d Sliding Doors: Suspended from overhead ball bearing rollers, which are noiseless and
self-lubricating, and ride in stainless steel guide strips fitted with die formed, recessed
pulls securely welded in place.
d Shelves: Constructed with a channel shaped, flanged edge and centers the full height
of the cabinet.
d Drawers: Drawer bodies are a one piece construction with covered corners. Drawer
face equipped with die cast aluminum bar pole handles. Drawers operated on ball
bearing roller slides with full extension.
• High Cabinets & Wall Cabinets: Recessed pan back,
3
/
4
” deep.
• Base Cabinets: Each applied with a channel shaped base, incorporating toe space
approximating 3” deep and 4” high, for easy cabinet access. Can be omitted when recessed
or another base is used.
• Sinks and Countertops: Fabricated in one piece, where possible, with welded corners,
channel shaped exposed edges, and reinforced with three full length hat shaped galvanneal
channels.
Cabinets
CASEWORK
Construction
Specifications
Shipping Information
All shipping weights are estimates and may be changed without prior notice. Specifications
may be improved and dimensions changed without prior notice. Please contact customer
service for estimated shipping costs at [e-mail].
