Exploded Views and Parts List
Samsung Electronics 8-7
Loc. No Parts No. Description ; Specification Remark
201 AH91-60117A ASSY-DECK CLAMPER;DVD860,-,DP-1
202 AH92-00035A ASSY-PCB-DECK;DP-3,-
203 3809-001125 CABLE-FLAT;30V,80C,140MM,8P,1MM,UL2896
204 AH91-60147A ASSY-BRKT DECK;DP-3,DVD-909,-
205 AH66-90054A TRAY-DVD;DP,ABS,-,BLK,-,DP-1
206 AH91-60154A ASSY-DECK HOUSING;DP-3,DVD-909,-
207 AH66-30087A LEVER-OPEN SW;DP,KEPITAL,T0.7,L26,F20-03
208 AH66-20194A GEAR-CAM CENTER;DP,KEPITAL F20-03,M1.2,Z
209 AH66-20183A GEAR-CAM SUB;DP,KEPITAL FT2020,M1,2,Z7,-
210 AH66-20185A GEAR-TRAY A;DP,KEPITAL F20-03,M0.4/M0.5,
211 AH66-10024A PULLEY-GEAR;DP,KEPITAL F20-03,BLK,DP-1
212 AH66-60033A BELT-PULLEY;DP,CR,T1.5,0.08,L82.7,BLK,DP
213 AH66-20184A GEAR-TRAY;DP,KEPITAL F20-03,M0.5/M0.6,Z4
214 AH97-00178A ASSY-BRKT FEED;DP-3,-,SOH-DP1
215 BG61-20031A HOLDER-CAM;-,POM,-,-,-,DDR-4
216 AH61-50327A SHAFT-P/U;DP,SUS420J2,OD3,L84.7,S/FINISH
217 AH66-20228A RACK-SLIDE;DP,KEPITAL F20-03,WHT,M0.4,P1
218 AH30-20001B PICK-UP;SPU-DP1 DVD-909
219 AH91-60151A ASSY-MOTOR SPINDLE;DP-3,DVD-909,-
220 AH60-30020A WASHER-PLAIN;DP,-,ID3.1,OD6,T0.3,RED COL
221 AH91-60120A ASSY-GEAR-FEED-AU/AL;DP-1,DVD-860,-
222 AH66-20182A GEAR-FEED B;DP,KEPITAL F20-03,M0.4,Z44,W
223 AH91-60121A ASSY-GEAR-FEED-CU/CL;DP-1,DVD-860,-
224 AH63-30245B COVER-sheet;-,-,-,T0.7,CLR,-,BLK CARBON,
225 AH73-10017A RUBBER-INSULATOR;RUBBER(LB-40),OD11,DP-1
227 3809-001123 CABLE-FLAT;30V,80C,90MM,40P,1.25MM,UL289
229 AH61-50323A SHAFT-SYNCRO;-,sus304,2.1,119,-,-,dvd-90
230 AH66-22005A GEAR-SYNCRO-A;KEPITAL F20-03,M0.8,Z9,-,P
231 AH97-00179A ASSY-HOUSING MOTOR;DP-3,-,SOH-DP1
901 AH60-10151A SCREW-TAP TITE;DP,SPEC6.8 ,PH,+,CP,M2,L
902 AC60-10051A SCREW-TAPPING;BH,-,-,M3,L8,FZY
903 AH60-10143U SCREW-TAP TITE;DP,PH,+,SPEC,TAP1.7,L5,ZP
904 AH60-10145A SCREW-TAP TITE;DP,PH,+,SPEC OD5.5 FP,TAP
905 AH60-10147A SCREW-MACHINE;DP,CH,+,FP,M2,L4,ZPC,SWRCH
906 AC60-10059A SCREW-TAPPING;BH,+,-,1.7,X5,ZPC2
907 AH60-00010A SCREW-MACHINE-MOTOR;-,+,SWCH18AK,M1.7,L2
908 AC60-10042A SCREW-TAPPING;PWH,+,-,M3,L8,-
909 BG60-10020A SCREW-SP MOTOR;-,BHW TOOTH,-,-,M1.7,L3,-
