Service manual

Exploded Views and Parts List
Samsung Electronics 8-5
Loc. No Parts No. Description ; Specification Remark
1 Refer to table below ASSY-CABINET FRONT;DVD-709,ASSY,EXPORT
2 Refer to table below ASSY-DOOR TRAY;DVD-709,ABS
11 AH61-00194A HOLDER-DECK A;-,ABS 94HB,-,DVD-909
12 AH64-80001E FOOT-FRONT;-,ABS94,HB,T2,SIL,H/STAMP,DVD
13 AH61-00194B HOLDER-DECK B;-,ABS 94HB,-,BLK,-,DVD-909
14 AH61-00194C HOLDER-DECK C;-,ABS 94HB,-,BLK,-,DVD-909
101 Refer to table below ASSY-CABINET TOP;DVD-709,ABS
150 Refer to table below SCREW-TAPTITE;BH,+,B,M3,L10,BLK,SWCH1018
151 6003-000276 SCREW-TAPTITE;BH,+,B,M3,L10,ZPC(YEL),SWC
601 Refer to table below ASSY-PCB-MAIN;DVD-709,MAIN PCB
602 Refer to table below ASSY-PCB-JACK;DVD-709,JACK PCB
605 AH63-00040A GROUND-REAR;-,PBS,T0.2,-,DVD-909
610 AH39-00034A POWER CORD;-,1.83M,CONNECTOR (EP-2) NORTH AMERICA
AH39-00129A POWER CORD;-,1.83M,CONNECTOR LATIN AMERICA
AH39-00042A POWER CORD;-,1.83M,CONNECTOR (BS) U.K
AH39-10002R POWER CORD;-,1.83M,CONNECTOR (AP-2) AUSTRALIA
AH39-00041A POWER CORD;-,1.83M,CONNECTOR (CP-2) COMMON
701 AH92-00167A ASSY-PCB-POWER;DVD-709,POWER
702 AH92-00166A ASSY-PCB-PLAY;DVD-709,PLAY
CN11A 3809-001133 CABLE-FLAT;30V,80C,200MM,35P,1.25MM,UL28
UT01 Refer to table below REMOCON-ASS’Y;-,-,-,48,DVD-909,S.S
REGIONAL NUMBER 1 2 101 150 601 602 UT01
1 AH95-10355A AH95-50369C AH97-00188A 6003-000275 AH92-00056A AH92-00057A AH59-10141A
2
EUROPE AH95-10355C AH95-50369A AH97-00188C AH60-00025A AH92-00058A AH92-00059A AH59-10141B
TRKEY AH95-10355L AH95-50369C AH97-00188C AH60-00025A AH92-00058A AH92-00059A AH59-10141B
4 AH95-10355C AH95-50369A AH97-00188C AH60-00025A AH92-00450A AH92-00273A AH59-10141B
5 AH95-10355C AH95-50369A AH97-00188C AH60-00025A AH92-00439A AH92-00440A AH59-10141B
