Service manual

Operating Instructions
Samsung Electronics 4-7
OPTICAL COAXIAL
DIGITAL AUDIO OUT ANALOG AUDIO OUT MIXED AUDIO OUT
R FRONT L
R SURROUND L
CENTER R1
R2
L1 L2
S/W
VIDEO OUT S-VIDEO OUT
V1 V2
TV SYSTEM SELECT
NTSC SECAM
PAL
AV1 AV2
Description-Rear Panel
DVD-909
Rear Panel
DIGITAL AUDIO OUT JACK • Use either an optical or coaxial digital cable to connect to a
compatible Dolby Digital receiver. Use to connect to an A/V Amplifier that contains the Dolby Digital decoder or DTS decoder.
5.1CH ANALOG AUDIO OUT JACKS • Connect to an amplifier with 5.1ch analog input jacks. MIXED AUDIO OUT JACKS • Connect to the Audio input jacks of your television, audio/video
receiver, or VCR.
VIDEO OUT JACKS • Use a video cable to connect one of these jacks to the Video
input on your television.
S-VIDEO OUT JACK • Use the S-Video cable to connect this jack to the S-Video jack
on your television for a higher quality picture.
TV SYSTEM SELECT SWITCH • Use the switch to set TV system. SCART AV1 JACK • Connect to a TV with scart input jack. SCART AV2 JACK • Connect to a video recorder or other equipment.
DIGITAL
AUDIO OUT
ANALOG AUDIO OUT
R L
VIDEO OUT S-VIDEO OUT
TV SYSTEM SELECT
NTSC SECAM
PAL
AV
Description-Rear Panel
DIGITAL AUDIO OUT JACK • Use a coaxial digital cable to connect to an A/V Amplifier that
contains a Dolby Digital decoder or DTS decoder.
ANALOG AUDIO OUT JACKS • Connect to the Audio input jacks of your television, audio/video
receiver, or VCR.
VIDEO OUT JACK • Use a video cable to connect this jack to the Video input on
your television.
S-VIDEO OUT JACK • Use the S-Video cable to connect this jack to the S-Video jack
on your television for a higher quality picture.
TV SYSTEM SELECT SWITCH • Use the switch to set TV system. SCART AV JACK • Connect to a TV with scart input jack.
DVD-709
Rear Panel
SCART JACK
