Service manual

Product Specification
3-2 Samsung Electronics
Power Requirements AC 110V ~ 240V, 50/60Hz
Power Consumption DVD-909 ; 19W, DVD-709 ; 17W
GENERAL
Weight 3.4Kg
Dimensions W 430mm X D 280mm X H 89mm
Operating Temperature Range +5°C ~ 35°C
Operating Humidity Range 10% ~ 75%
DVD Reading Speed : 3.49m/sec.
(Digital Versatile Disc) Approx. Play Time (Single Sided, Single Layer Disc) : 135 min.
CD : 12cm Reading Speed : 1.2 to 1.4m/sec.
DISC
(Compact Disc) Maximum Play Time : 74min.
CD : 8cm Reading Speed : 1.2 to 1.4m/sec.
(Compact Disc) Maximum Play Time : 20min.
VCD : 12cm
Reading Speed : 1.2 to 1.4m/sec.
Maximum Play Time : 74min. (Video + Audio)
R (Red) : 0.714Vp-p (75ohm load)
Scart Jack (Option)
G (Green) : 0.714Vp-p (75ohm load)
B (Blue) : 0.714Vp-p (75ohm load)
Video Output
Composite Video : 1.0Vp-p (75ohm load)
Composite Video - DVD-909 ; 2 channel : 1.0Vp-p (75ohm load) DVD-709 ; 1 channel : 1.0Vp-p (75ohm load)
Component Video Y : 1.0Vp-p (75ohm load) ; <DVD-909 Only>
RCA-Jack (Option) Pr : 0.70Vp-p (75ohm load) ; <DVD-909 Only>
Pb : 0.70Vp-p (75ohm load) ; <DVD-909 Only>
RCA-Jack
Component Video Channel : 1.0Vp-p (75ohm load) ; <DVD-709 Only>
2 Channel : 1.0Vp-p (75ohm load) ; <DVD-909 Only>
S-Video
Luminance Signal : 1Vp-p (75ohm load)
Color Signal : 0.286Vp-p (75ohm load)
Scart Jack 2 Channel : L, R
RCA-Jack
2 Channel : L (1/L), R (2/R)
5.1 Channel : F/L, L/R, R/L, R/R, C/T, S/W - (DVD-909 Only)
Analog : 2Vrms (1KHz, 0dBFS)
Output Level Digital : DVD-709 ; 500mVp-p (Coxial)
Audio Output DVD-909 ; 500mVp-p (Coxial), 1.15Vp-p (Optical)
* Frequemvy Response
48KHz Sampling : 4Hz to 22KHz
96KHz Sampling : 4Hz to 44KHz
* S/N Ratio 110dB
* Dynamic Range 96dB
* Total Harmonic Distortion 0.003%
* : Nominal specification
P A L
