CHANGING
SETUP MENU
4.
4.
Setting Up Display Options (Cont d)
DD
DD
VV
VV
DD
DD
39
4.
4.
Use the UP/DOWN button to select the desired
item. Then press the ENTER button.
TV ASPECT
4:3 LETTER BOX :
Select when you want to see the total 16:9 ratio screen DVD
supplies, even though you have a TV with a 4:3 ratio screen.
Black bars will appear at the top and bottom of the screen.
4:3 PAN-SCAN :
Select this for conventional size TVs when you want to see the
central portion of the 16:9 screen. (Extreme left and right side of
movie picture will be cut off.)
16:9 WIDE :
You can view the full 16:9 picture in your widescreen TV.
ANGLE MARK
ON : Displays ANGLE MARK in the upper right corner of
screen.
OFF : Doesn’t display it.
STILL MODE
FIELD : Select this feature when the screen shakes in the
AUTO mode.
FRAME : Select this feature when you want to see small let-
ters more clearly in the AUTO mode.
AUTO : When selecting AUTO, FIELD/FRAME mode will be
automatically converted.
SCREEN MESSAGES
Use this feature to turn the on-screen displays that appear in
screen on or off.
FRONT DISPLAY
BRIGHT : It makes the Front Panel Display bright.
DIM : It makes the Front Panel Display dim.
AUTO DIM : It makes the Front Panel Display dim automati-
cally when playing a DVD.
BLACK LEVEL
Adjust the brightness of screen.
QUASI-PAL
Depending on a disc, you can play a NTSC DVD disc by
QUASI-PAL mode.
SCART OUT
RGB : If "RGB" has been selected, RGB signal will emit from
the AV JACK(SCART terminal).
VIDEO : If "VIDEO" has been selected, COMPOSITE VIDEO
signal will emit from the AV JACK(SCART terminal).
S-VIDEO : If "S-VIDEO" has been selected, S-VIDEO signal
will emit from the AV JACK(SCART terminal).
1
2
3
1
2
1
1
2
3
1
2
3
2
3
NOTE
• If you change the INPUT of TV from VIDEO mode to TV mode while the DVD player's power is on and the SCART OUT has been
selected to "RGB", TV screen might not appear in a normal mode. Then please watch TV with the DVD player turned off.
• When you playback 16:9 encoded DVD disc on a 4:3 TV when SCART OUT selection is "RGB" and TV ASPECT selection is "16:9
WIDE", TV screen might not appear in normal mode. Then please set the SCART OUT to "VIDEO" or change the TV ASPECT to
"4:3 LETTER BOX" or "4:3 PAN-SCAN".
