Service manual

U sing the Zoom and 3D Sound
DD
DD
VV
VV
DD
DD
//
//
VV
VV
CC
CC
DD
DD
Using the Zoom Function (DVD/VCD)
Using the 3D Sound Function
The simulated surround effect (SPATIALIZER N-2-2)
depends on the disc contents. If you connect the
unit to your stereo system, you can enhance sound
quality and produce a greater surround effect.
This feature is useful when you are using the DVD
player with a two channel stereo through the analog
outputs.
(Discs which are recorded with LPCM or DTS will
not work. When the DOLBY DIGITAL OUT or
MPEG-2 DIGITAL OUT is set to BITSTREAM in the
SETUP MENU, the 3D Sound function will not
work.)
1
1
During playback, press the 3D SOUND button.
The 3D SOUND mark will be displayed on
screen. (Be sure the DOLBY DIGITAL OUT
and MPEG-2 DIGITAL OUT are set to PCM.)
2
2
Press the LEFT/RIGHT button to turn the 3D
Sound feature on or off.
1.
1.
During playback or pause mode, press the
ZOOM button on the remote. The square
frame will be displayed on screen.
2.
2.
Use the UP/DOWN or LEFT/RIGHT button to
select the part of the screen you want to zoom.
3.
3.
Press the ENTER button.
- During DVD playback, press ENTER to zoom in 2X/4X/nor-
mal in order.
- During VCD playback, press ENTER to zoom in 2X/normal
in order.
31
1.
1.
1
1
2.,2
2.,2
ADVANCED
FUNCTIONS
NOTE
• 3D Sound is possible only on discs recorded using DOLBY SURROUND or DOLBY DIGITAL. However, some of these discs do not
contain the rear sound signal.
• Depending on the disc, the Zoom and 3D Sound function may not work.
• Certain audio feature of this product manufactured under a license from Desper Products, Inc., Spatializer
®
and circle-in-square are
trademarks owned by Desper Products Inc.
• DTS : A digital surround sound format that, like Dolby Digital, provides six separate audio channels. To hear a DTS soundtrack, you
must connect the player's DIGITAL AUDIO OUT jack to a compatible DTS-equipped receiver.
• LPCM : Linear Pulse Code Modulation-a digital recording process.
Using the Master Volume Control Function
Press the VOLUME CON. button. Use the UP/DOWN button to
select a suitable volume.
• Master Volume Control function lets you adjust the volume of the
player's output. This is useful for matching the player's output level
to other equipment in your system.
• Master Volume Control function on CD titles with DTS will not work
under VOLUME : 96 level.
• When the Dolby DIGITAL OUT or MPEG-2 DIGITAL OUT is set to
BITSTREAM in the SETUP MENU, the Volume Control function
will not work.
