CONNECTIONS
C hoosing a Connection
The following diagrams show common connection examples that can be used for connecting your DVD player
to a TV or other equipment.
DVD-909
Before Connecting the DVD Player Connecting to a TV (For Video)
MIXED AUDIO OUT
R1
R2
L1
RL
L2
VIDEO OUT
S-VIDEO OUT
V1
V2
AV1
TV
DVD
PLAYER
15
Connecting to a TV
• Method 1
DVD Player + TV with Video Input Jack
• Method 2
DVD Player + TV with S-Video Input Jack
• Method 3
DVD Player + TV with Scart Input Jack (Audio &
Video)
• Always turn off the DVD player, TV, and other
components before you connect or disconnect any
cables.
• Refer to owner’s manual of the components you
are connecting for more information on those par-
ticular components.
TV (Normal, Widescreen, Projection, etc..)
Good
Basic Audio
(In case of
Method 1 or 2)
OR OR
AV Cable
(included)
S-Video
Cable
(included)
Scart Cable
(not included)
Better
Best picture
(If RGB is selected in
SETUP MENU)
Video Input JackAudio Input Jacks S-Video Jack Scart Input Jack
Method 1 Method 2 Method 3
