D escription-Rear Panel
DIGITAL AUDIO OUT JACK
• Use a coaxial digital cable to connect to an A/V Amplifier that
contains a Dolby Digital decoder or DTS decoder.
ANALOG AUDIO OUT JACKS
• Connect to the Audio input jacks of your television, audio/video
receiver, or VCR.
VIDEO OUT JACK
• Use a video cable to connect this jack to the Video input on
your television.
S-VIDEO OUT JACK
• Use the S-Video cable to connect this jack to the S-Video jack
on your television for a higher quality picture.
TV SYSTEM SELECT SWITCH
• Use the switch to set TV system.
SCART AV JACK
• Connect to a TV with scart input jack.
11
DVD-709
Rear Panel
