Service manual

PIC2 0604-000186 PHOTO-COUPLER;TR,-,200mW,DIP-4,ST
PIC3 AC14-12006D IC;KA431Z,TO-92,TAPING
PIC4 1203-000122 IC-NEGA.FIXED REG.;7908,TO-220,3P,-,PLAS
PIC5 1203-001697 IC-VOLTAGE REGULATOR;78R08,TO-220,4P,-,P
PIC6 1203-001083 IC-VOLTAGE REGULATOR;3RF23,TO-202,4P,12.
PL01 AC29-30050A FILTER-LINE NOISE;-,400UH,-,250V,-
PL02 AC27-92001Q COIL-LINE FILTER;BSF-2120Z,25MH,-,-,-
PL03 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
PL11 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
PQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92 NTSC ONLY
PQ2 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L NTSC ONLY
PQ21 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
PQ22 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-
PQ23 0502-000298 TR-POWER;KSD73,NPN,30W,TO-220,-,120-240
PQ24 0502-000298 TR-POWER;KSD73,NPN,30W,TO-220,-,120-240
PQ3 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO- NTSC ONLY
PQ4 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T NTSC ONLY
PR10 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,ST,7.5x11x20.
PR11 2001-000073 R-CARBON;33KOHM,5%,1/4W,AA,TP,2.4X6.4MM
PR12 2001-000073 R-CARBON;33KOHM,5%,1/4W,AA,TP,2.4X6.4MM
PR13 2001-000073 R-CARBON;33KOHM,5%,1/4W,AA,TP,2.4X6.4MM
PR14 2001-000073 R-CARBON;33KOHM,5%,1/4W,AA,TP,2.4X6.4MM
PR15 2003-000273 R-METAL OXIDE;33Kohm,5%,2W,AA,TP,6x16mm
PR16 2003-000273 R-METAL OXIDE;33Kohm,5%,2W,AA,TP,6x16mm
PR17 2003-000148 R-METAL OXIDE;100OHM,5%,2W,AE,TP,6X16MM
PR18 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3.2MM
PR2 2003-000148 R-METAL OXIDE;100OHM,5%,2W,AE,TP,6X16MM
PR20 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR3 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3 NTSC ONLY
PR31 2001-000034 R-CARBON;220OHM,5%,1/4W,AA,TP,2.4X6.4MM
PR32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR33 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR34 2001-000440 R-CARBON;1OHM,5%,1/8W,AA,TP,1.8X3.2MM
PR35 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
PR36 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR37 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PR38 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm
PR39 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
PR4 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 NTSC ONLY
PR40 2003-000111 R-METAL OXIDE;0.47ohm,5%,1W,AD,TP,4.3x12
PR5 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 NTSC ONLY
PR6 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 NTSC ONLY
PR7 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM PAL ONLY
PT01 AH26-00008A TRANS-SWITCHING;-,85V-240V,UL/CSA,EE2821
PVA01 1405-000186 VARISTOR;470V,4500A,17x12mm,TP
PZD31 0403-000717 DIODE-ZENER;MTZJ5.1B,5.1V,4.94-5.2V,500m
RC12 2201-000812 C-CERAMIC,DISC;2.2nF,20%,400V,Y5U,BK,11x
RC13 2201-000812 C-CERAMIC,DISC;2.2nF,20%,400V,Y5U,BK,11x
RL03 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
SCC1 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V, DVD-909 PAL ONLY
SCC10 2203-000239 C-CERAMIC,CHIP;100pF,5%,50V,NPO, DVD-909 PAL ONLY
SCC11 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V PAL ONLY
SCC12 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, PAL ONLY
SCC13 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V, DVD-909 PAL ONLY
SCC14 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, PAL ONLY
SCC2 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V DVD-909 PAL ONLY
SCC3 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP PAL ONLY
SCC4 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP PAL ONLY
SCC5 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P DVD-909 PAL ONLY
SCC6 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P, DVD-909 PAL ONLY
SCC7 2203-000239 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP, DVD-909 PAL ONLY
SCC8 2203-000239 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP, DVD-909 PAL ONLY
SCC9 2203-000239 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP, DVD-909 PAL ONLY
SCD1 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2- DVD-909 PAL ONLY
SCD2 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- PAL ONLY
SCD3 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- PAL ONLY
SCE1 2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5 DVD-909 PAL ONLY
SCE10 2401-000369 C-AL;100UF,20%,6.3V,GP,-,6.3X11,5 PAL ONLY
SCE11 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11mm,2.5m PAL ONLY
SCE12 2401-000369 C-AL;100UF,20%,6.3V,GP,-,6.3X11,5 PAL ONLY
SCE13 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11mm,2.5m PAL ONLY
SCE14 2401-000369 C-AL;100UF,20%,6.3V,GP,-,6.3X11,5 PAL ONLY
SCE15 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11mm,2.5m PAL ONLY
SCE16 2401-002042 C-AL;220uF,20%,10V,GP,TP,6.3x11,5 PAL ONLY
SCE17 2401-001353 C-AL;470uF,20%,10V,GP,TP,8x11.5,5 PAL ONLY
SCE2 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11mm,2.5m DVD-909 PAL ONLY
SCE3 2401-000369 C-AL;100UF,20%,6.3V,GP,-,6.3X11,5 DVD-909 PAL ONLY
SCE4 2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5 PAL ONLY
SCE5 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11mm,2.5m PAL ONLY
SCE6 2401-000369 C-AL;100UF,20%,6.3V,GP,-,6.3X11,5 PAL ONLY
SCE7 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 PAL ONLY
SCE8 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 PAL ONLY
SCE9 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 PAL ONLY
SCIC1 AH14-10004T IC-ANALOG M/PLEXER;MC14053BD,SOP , DVD-909 PAL ONLY
SCIC2 AH14-10004T IC-ANALOG M/PLEXER;MC14053BD,SOP, DVD-909 PAL ONLY
SCIC3 AH14-10004T IC-ANALOG M/PLEXER;MC14053BD,SOP,TAPE 16 PAL ONLY
SCIC4 1201-001063 IC-OP AMP;2267,SOP,8P,300MIL,DUAL,6.7dB, PAL ONLY
SCIC5 AH14-10004T IC-ANALOG M/PLEXER;MC14053BD,SOP, DVD-909 PAL ONLY
SCIC6 1201-001419 IC-VIDEO AMP;7660,SSOP,16P,173MIL,3,6DB, PAL ONLY
SCJ1 3722-001354 JACK-SCART;42P/2R,-,SN,BLK,- PAL ONLY
SCL1 2701-000181 INDUCTOR-AXIAL;33UH,5%,2.4X3.4MM PAL ONLY
SCL10 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,- PAL ONLY
SCL11 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,- PAL ONLY
SCL2 2701-000181 INDUCTOR-AXIAL;33UH,5%,2.4X3.4MM PAL ONLY
SCL3 2701-000181 INDUCTOR-AXIAL;33UH,5%,2.4X3.4MM DVD-909 PAL ONLY
SCL4 2701-000181 INDUCTOR-AXIAL;33UH,5%,2.4X3.4MM DVD-909 PAL ONLY
SCQ1 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP PAL ONLY
SCQ10 0504-000156 TR-DIGITAL;DTA124EKA,PNP,200mW,22K DVD-909 PAL ONLY
SCQ11 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP PAL ONLY
SCQ12 0504-000156 TR-DIGITAL;DTA124EKA,PNP,200mW,22K-22K DVD-909 PAL ONLY
SCQ13 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23, DVD-909 PAL ONLY
SCQ14 0504-000156 TR-DIGITAL;DTA124EKA,PNP,200mW,22K DVD-909 PAL ONLY
SCQ17 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT- PAL ONLY
SCQ18 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT- PAL ONLY
SCQ19 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT- PAL ONLY
SCQ2 0504-000156 TR-DIGITAL;DTA124EKA,PNP,200mW,22K-22K PAL ONLY
SCQ3 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP PAL ONLY
SCQ4 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP PAL ONLY
SCQ5 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, PAL ONLY
SCQ6 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT- PAL ONLY
SCQ7 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, PAL ONLY
SCQ8 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP PAL ONLY
SCQ9 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23 DVD-909 PAL ONLY
SCR1 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM PAL ONLY
SCR10 2007-001118 R-CHIP;680OHM,5%,1/10W,DA,TP,2012 PAL ONLY
SCR11 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM PAL ONLY
SCR12 2001-000958 R-CARBON;750OHM,5%,1/8W,AA,TP,1.8X3.2MM PAL ONLY
SCR13 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM PAL ONLY
SCR14 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM PAL ONLY
SCR15 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM PAL ONLY
SCR16 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM PAL ONLY
SCR17 2001-000958 R-CARBON;750OHM,5%,1/8W,AA,TP,1.8X3.2MM PAL ONLY
SCR18 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 PAL ONLY
SCR19 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3 PAL ONLY
SCR2 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012 DVD-909 PAL ONLY
SCR20 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3 PAL ONLY
SCR21 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 PAL ONLY
SCR22 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 PAL ONLY
SCR23 2007-001201 R-CHIP;820OHM,5%,1/10W,DA,TP,2012 DVD-909 PAL ONLY
SCR24 2007-001201 R-CHIP;820OHM,5%,1/10W,DA,TP,2012 DVD-909 PAL ONLY
SCR25 2007-001166 R-CHIP;75OHM,5%,1/10W,DA,TP,2012 DVD-909 PAL ONLY
SCR26 2007-001201 R-CHIP;820OHM,5%,1/10W,DA,TP,2012 DVD-909 PAL ONLY
Electrical Parts List
Samsung Electronics
9-9
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
