AR121 2007-001247 R-CHIP;91OHM,5%,1/10W,DA,TP,2012
AR13 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012
AR130 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR131 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3. DVD-909 ONLY
AR132 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3. DVD-909 ONLY
AR133 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3. DVD-909 ONLY
AR134 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR138 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
AR14 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012
AR15 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR150 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR151 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR152 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR153 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR154 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR155 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR156 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR18 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR19 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR2 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR20 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR21 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR22 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR23 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR24 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012
AR25 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012
AR26 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012
AR27 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR28 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR29 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR30 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR31 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR32 2007-000766 R-CHIP;330OHM,5%,1/10W,DA,TP,2012
AR33 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR34 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR35 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR36 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR37 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR38 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR39 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR40 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR41 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR42 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR43 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR44 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR45 2007-000766 R-CHIP;330OHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR46 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR47 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR48 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR49 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR50 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR51 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR52 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR53 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR54 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR55 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR56 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR57 2007-000766 R-CHIP;330OHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR58 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR59 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR60 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR61 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR62 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR63 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR64 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR65 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR66 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR67 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR68 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR69 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR70 2007-000766 R-CHIP;330OHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR71 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR72 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR73 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR74 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR75 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR76 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR77 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR78 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR79 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR8 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012
AR80 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR81 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR82 2007-000766 R-CHIP;330OHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR83 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR84 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR85 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR86 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR87 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR88 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR89 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR9 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3
AR90 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3
AR91 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3
AR92 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3
AR93 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR94 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR95 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR96 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR97 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3 DVD-909 ONLY
AR98 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AR99 2007-001055 R-CHIP;6.2KOHM,5%,1/10W,DA,TP,2012 DVD-909 ONLY
AVJ1 3722-001355 JACK-RCA;3P(4P),3.2MM,NI,GRN/RED/ DVD-909 NTSC ONLY
AVJ2 3722-001353 JACK-RCA;6P,3.2MM,NI,YEL/WHT/RED,- DVD-909 ONLY
AVJ3 3722-001352 JACK-RCA;6P,3.2MM,NI,BLK/WHT/RED,- DVD-909 ONLY
AVJ4 3722-001053 JACK-RCA;1P,3.2mm,NI,BLK,-
AVJ5 3707-001005 CONNECTOR-OPTICAL;PLUG,SM,-,4.4/2.0MM DVD-909 ONLY
AZD1 0403-000551 DIODE-ZENER;MTZ3.9B,3.9V,3.89-4.16V,500m
CN11 3708-000277 CONNECTOR-FPC/FC/PIC;35P,1.25mm,ANGLE,SN
CN12 AH39-00035A LEAD CONNECTOR-ASSY;-,5264-08,35023-08,8
CN15 3711-000665 CONNECTOR-HEADER;BOX,12P,1R,2mm,ANGLE DVD-909 ONLY
CN17 AH39-00037A LEAD CONNECTOR-ASSY;-,51004-06,35023-06, DVD-909 ONLY
CN18 3711-000967 CONNECTOR-HEADER;BOX,4P,1R,2mm,ANGLE,SN
FC1 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
FC10 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
FC14 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
FC15 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
FC16 2202-000173 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,1
FC2 2203-000389 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,2012,-
FC3 2203-000389 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,2012,-
FC4 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
FC6 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
FD10 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
FD6 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
FD7 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
FD8 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
FD9 0403-000551 DIODE-ZENER;MTZ3.9B,3.9V,3.89-4.16V,500m
FE1 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11mm,2.5m
FE12 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
FE13 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
FE2 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
FE5 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
