Service manual

VR57 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
VR58 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
VR59 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
VR60 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
VR61 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
VR62 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
VR63 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
VR64 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
VR65 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
VR66 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR67 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR68 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR69 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR7 2007-000116 R-CHIP;120ohm,5%,1/16W,DA,TP,1608
VR70 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR71 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR72 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR73 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR74 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR75 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR76 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR77 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR78 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR79 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR80 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR81 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VR82 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
VR83 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR84 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR85 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR86 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR87 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR88 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR89 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR9 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
VR90 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR91 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR92 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR93 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR94 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR95 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR96 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR97 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR98 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
VR99 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
VY1 2801-003554 CRYSTAL-UNIT;27MHz,10ppm,28-AAM,12pF,40o
602 ASSY-PCB-JACK
AC1 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC10 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,-
AC11 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
AC12 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012,
AC16 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC17 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC18 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V, DVD-909 ONLY
AC19 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,- DVD-909 ONLY
AC2 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC20 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY
AC21 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY
AC22 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC23 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC25 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,- DVD-909 ONLY
AC26 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP DVD-909 ONLY
AC27 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY
AC29 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC3 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
AC30 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC31 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V DVD-909 ONLY
AC32 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,- DVD-909 ONLY
AC33 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY
AC34 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY
AC35 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC36 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC38 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,- DVD-909 ONLY
AC39 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP DVD-909 ONLY
AC4 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,-
AC40 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY
AC42 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC43 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC44 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC45 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,- DVD-909 ONLY
AC46 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY
AC47 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY
AC48 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC49 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC5 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012,
AC51 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,- DVD-909 ONLY
AC52 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP DVD-909 ONLY
AC53 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012, DVD-909 ONLY
AC56 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC57 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, DVD-909 ONLY
AC58 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC59 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
AC6 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012,
AC60 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
AC61 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V DVD-909 ONLY
AC7 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC71 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC73 2301-000161 C-FILM,PEF;12nF,5%,50V,6.5X5.5X3.0X5,5mm
AC74 2301-000161 C-FILM,PEF;12nF,5%,50V,6.5X5.5X3.0X5,5mm
AC75 2301-000161 C-FILM,PEF;12nF,5%,50V,6.5X5.5X3.0X5,5mm DVD-909 ONLY
AC76 2301-000161 C-FILM,PEF;12nF,5%,50V,6.5X5.5X3.0X5,5mm DVD-909 ONLY
AC77 2301-000161 C-FILM,PEF;12nF,5%,50V,6.5X5.5X3.0X5,5mm DVD-909 ONLY
AC78 2301-000161 C-FILM,PEF;12nF,5%,50V,6.5X5.5X3.0X5,5mm DVD-909 ONLY
AC79 2301-000161 C-FILM,PEF;12nF,5%,50V,6.5X5.5X3.0X5,5mm DVD-909 ONLY
AC8 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC80 2301-000161 C-FILM,PEF;12nF,5%,50V,6.5X5.5X3.0X5,5mm DVD-909 ONLY
AC90 2202-000849 C-CERAMIC,MLC-AXIAL;18pF,5%,50V,CH,TP,3.
AC91 2202-000849 C-CERAMIC,MLC-AXIAL;18pF,5%,50V,CH,TP,3. DVD-909 ONLY
AC92 2202-000849 C-CERAMIC,MLC-AXIAL;18pF,5%,50V,CH,TP,3. DVD-909 ONLY
AC93 2202-000849 C-CERAMIC,MLC-AXIAL;18pF,5%,50V,CH,TP,3. DVD-909 ONLY
Electrical Parts List
Samsung Electronics
9-5
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
