VC28 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC29 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC3 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC30 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC31 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC32 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC33 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC34 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC35 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC36 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC37 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC38 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC39 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC4 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC40 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC41 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC42 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC43 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC44 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC45 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC47 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC48 2203-000681 C-CERAMIC,CHIP;27pF,5%,50V,NPO,1608,-,TP

VC5 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC50 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC51 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC52 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC53 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC54 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC55 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

VC6 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC61 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1

VC62 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1

VC65 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1

VC66 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1

VC67 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1

VC68 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1

VC69 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC7 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC70 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC71 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC72 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC73 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC74 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC75 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC76 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC77 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC78 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-

VC8 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VC81 2203-000851 C-CERAMIC,CHIP;39pF,5%,50V,NPO,TP,1608,-

VC82 2203-000851 C-CERAMIC,CHIP;39pF,5%,50V,NPO,TP,1608,-

VC83 2203-001071 C-CERAMIC,CHIP;56pF,5%,50V,NPO,TP,1608,-

VC84 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,

VC85 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,

VC9 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,

VE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5

VE2 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5

VIC1 1204-001438 IC-DECODER;ZIVA-3,VQFP,208P,1098MIL,PLAS

VIC10 1105-001165 IC-SDRAM;416S1020,512Kx16BITx2,TSOP,50P NTSC

VIC10 1105-001259 IC-DRAM;416S1020,16BIT,TSOP,50P,400MIL,8 PAL

VIC3 0801-002097 IC-CMOS LOGIC;7SET08,AND GATE,SOP,5P,110

VIC4 1105-001165 IC-SDRAM;416S1020,512Kx16BITx2,TSOP,50P NTSC

VIC4 1105-001259 IC-DRAM;416S1020,16BIT,TSOP,50P,400MIL,8 PAL

VIC6 AH14-10004R IC;M74HCU04,SOP,TAPE 14P

VL1 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL10 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012

VL11 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL12 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL13 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL14 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL15 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL16 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL17 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL18 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL19 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL2 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL20 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL21 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL22 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL23 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL24 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL25 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL26 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL27 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL28 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL29 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL3 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL4 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL5 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VL6 3301-000353 CORE-FERRITE BEAD;AB,2.0x1.25x0.9mm,-,-

VR10 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

VR100 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608

VR101 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608

VR102 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR103 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR104 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR2 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

VR21 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

VR22 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

VR23 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

VR24 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

VR25 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

VR26 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

VR27 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

VR28 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

VR3 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR30 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR31 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR32 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR33 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR34 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR35 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR36 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR37 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR38 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR39 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR4 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

VR40 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR41 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608

VR42 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR43 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR44 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR45 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR46 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR47 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR48 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR49 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR50 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR51 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR52 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR54 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR55 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608

VR56 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
